7. SEWING
49 KE-430D, BE-438D
7. SEWING
CAUTION
Turn off the power switch at the following times, otherwise the machine may operate if the foot switch is depressed
by mistake, which could result in injury.
• When threading the needle
• When replacing the needle and bobbin
• When not using the machine and when leaving the machine unattended
Do not touch any of the moving parts or press any objects against the machine while sewing, as this may result in
personal injury or damage to the machine.
1. Turn on the power switch.
2. Press the
or key (1) to select the number for the
program to be sewn.
3. Depress the foot switch to the 2nd step.
The feed mechanism will move to the home position.
4. Set the material under the work clamp (2).
(For the BE-438D, insert the button and place the
material under the button clamp (3). (Refer to “4-7.
Inserting the button”.)
5. Depress the foot switch to the 1st step.
The work clamp (2) / button clamp (3) will be lowered.
6. Depress the foot switch to the 2nd step.
The sewing machine will start sewing.
* If memory switch no. 003 is set to “ON”, the work clamp
(2)/button clamp (3) will drop to the intermediate stop
position when the foot switch is depressed to the 1st
step, and when it is depressed to the 2nd step, the
material will be held and sewing will start.
7. Once sewing is completed and the thread has been
trimmed, the work clamp (2) / button clamp (3) will rise.
4441Q
1st step
2nd step
4116M
4460Q
4459Q
To Next Page
