Brother MFC-J4335DW User Manual

Home > Security > Use LDAP Authentication > Configure LDAP Authentication Using Web Based
Management
Configure LDAP Authentication Using Web Based Management
Related Models: MFC-J4535DW
1. Start your web browser.
2. Type "https://machine's IP address" in your browser's address bar (where "machine's IP address" is the
machine's IP address).
For example:
https://192.168.1.2
3. If required, type the password in the Login field, and then click Login.
The default password to manage this machine’s settings is located on the back of the machine and marked
"Pwd".
4. Go to the navigation menu, and then click Administrator > User Restriction Function.
Start from , if the navigation menu is not shown on the left side of the screen.
5. Select LDAP Authentication.
6. Click Submit.
7. Click the LDAP Authentication menu.
8. Configure the following settings:
Option Description
Storage Fax RX Data Select this option to store incoming fax data. You can print all incoming fax
data after you log on to the machine.
Remember User ID Select this option to save your User ID.
LDAP Server Address Type the IP address or the server name (for example: ldap.example.com) of
the LDAP server.
Get User's Home Directory Select this option to obtain your home directory as the Scan to Network
destination.
LDAP Server Port Type the LDAP server port number.
LDAP Search Root Type the LDAP search root directory.
Attribute of Name (Search
Key)
Type the attribute you want to use as a search key.
9. Click Submit.
Related Information
• Use LDAP Authentication
Related Topics:
• Access Web Based Management
391

Brother MFC-J4335DW Specifications

General

Duplex printing	Yes
Print technology	Inkjet
Resolution color	1200 x 600 DPI
Maximum resolution	1200 x 4800 DPI
Print resolution black	1200 x 1200 DPI
Print speed (black, normal quality, A4/US Letter)	- ppm
Ethernet LAN	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Mopria Print Service
Total input capacity	150 sheets
Total output capacity	100 sheets
Total number of input trays	-
Auto document feeder (ADF) input capacity	20 sheets
Copier resize	25 - 400 %
N-in-1 copy function (N=)	2, 4
Fax memory	170 pages
Modem speed	14.4 Kbit/s
Scan to	Cloud, E-mail, File, OCR, PC
Scan drivers	TWAIN
Scanner type	Flatbed & ADF scanner
Scan speed (black)	17 ppm
Scan speed (color)	7 ppm
Image formats supported	JPEG, JPG
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	PDF
Optical scanning resolution	1200 x 2400 DPI
Power consumption (off)	0.2 W
Power consumption (ready)	3.5 W
Power consumption (sleep)	1.2 W
Power consumption (average operating)	21 W
Display	LCD
Product color	White
Display diagonal	1.8 \
Market positioning	Home & office
Internal memory	128 MB
Sound pressure level (printing)	53 dB
Sustainability certificates	Blue Angel
Printing colors	Black, Cyan, Magenta, Yellow
Duplex functions	Print
Maximum duty cycle	30000 pages per month
Recommended duty cycle	250 - 2000 pages per month
Number of print cartridges	4
Mac operating systems supported	Mac OS X 10.11 El Capitan, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Envelopes sizes	DL
Paper tray media types	Envelopes, Glossy paper, Plain paper, Recycled paper
Paper tray media weight	64 - 220 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5
Maximum ISO A-series paper size	A4
Package depth	242 mm
Package width	495 mm
Package height	455 mm
Package weight	10700 g
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	343 mm
Width	435 mm
Height	180 mm
Weight	8800 g
