Brother QL-720NW Quick Setup Guide

13
Before you install
Make sure your machine is connected to
the power and your Macintosh is ON.
You must be logged on with
Administrator rights.
Connect the USB cable
Installing the software for
USB interface cable
For USB interface users (Macintosh)
If you are connecting the printer to
Macintosh via a USB hub, it may not
be detected correctly. If so, connect
the printer directly to the USB port
on Macintosh.
1
IInsert the installer CD-ROM
into your CD-ROM drive.
2
Double-click the Start Here
OSX icon to install.
Available items:
Start Here OSX
Installs P-touch Editor 5.0,
P-touch Update Software
and the Printer Driver.
Utilities
Includes BRAdmin Light
and the Wireless Device
Setup Wizard.
Documentation
Includes the User’s Guide,
Software User’s Guide and
Network User’s Guide.
Brother Support
Displays the link to On-Line
Registration and Brother
Solutions Center.
3
Follow the on-screen
instructions.
4
After the installation is
completed, press the ON/
OFF button ( ) of the
machine to turn on the
power.
1
2
3
4

Brother QL-720NW Specifications

General

Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Maximum printing width	59 mm
Ethernet LAN	Yes
RS-232 ports	1
Connectivity technology	Wired & Wireless
Tape type	DK
Flash memory	6 MB
Number of styles	10
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, EAN128, EAN13, EAN8, ITF-14, MaxiCode, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Number of box types	6
Image formats supported	BMP, GIF, JPG, PNG, TIF
Dimensions (WxDxH)	128 x 236 x 153 mm
Maximum label width	62 mm
Maximum label length	1 m
Product color	Black

Weight and Dimensions

Weight	1200 g
