Brother QL-720NW Quick Setup Guide

35
This section explains how to start P-touch Editor Help for Windows
®
and Macintosh.
The following is the example for Windows Vista
®
. The printer names in the following
screens may differ from your printer name.
Start from Start ( ) button
To start P-touch Editor Help, click the
Start ( ) button on the task bar,
point to [All Programs].
Click [Brother P-touch] and
[P-touch Editor 5.0 Help].
Start from New/Open dialog
When you start the P-touch Editor 5.0 and the
New/Open dialog box appears, click
Help-How To
.
If you click "Check for update" in red square shown
right, you can check if the latest P-touch Editor is
available or not on the web site.
Start from P-touch Editor
Click Help menu and choose P-touch Editor Help.
Start from Snap mode
Right click the mouse and choose P-touch
Editor Help.
7 Start P-touch Editor Help
For Windows
®
Professional Mode
Express Mode

Brother QL-720NW Specifications

General

Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Maximum printing width	59 mm
Ethernet LAN	Yes
RS-232 ports	1
Connectivity technology	Wired & Wireless
Tape type	DK
Flash memory	6 MB
Number of styles	10
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, EAN128, EAN13, EAN8, ITF-14, MaxiCode, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Number of box types	6
Image formats supported	BMP, GIF, JPG, PNG, TIF
Dimensions (WxDxH)	128 x 236 x 153 mm
Maximum label width	62 mm
Maximum label length	1 m
Product color	Black

Weight and Dimensions

Weight	1200 g
