Brother QL-720NW Quick Setup Guide

36
The following is the example for Mac OS X 10.7. The printer names in the following
screens may differ from your printer name.
Start from New/Open dialog
When you start the P-touch Editor 5.0 and the
New/Open dialog box appears, click Help-How
To.
Start from P-touch Editor
Click Help menu and choose P-touch Editor
Help.
Start from Snap mode
Click the mouse with the control key held and
select P-touch Editor Help.
For Macintosh

Brother QL-720NW Specifications

General

Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Maximum printing width	59 mm
Ethernet LAN	Yes
RS-232 ports	1
Connectivity technology	Wired & Wireless
Tape type	DK
Flash memory	6 MB
Number of styles	10
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, EAN128, EAN13, EAN8, ITF-14, MaxiCode, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Number of box types	6
Image formats supported	BMP, GIF, JPG, PNG, TIF
Dimensions (WxDxH)	128 x 236 x 153 mm
Maximum label width	62 mm
Maximum label length	1 m
Product color	Black

Weight and Dimensions

Weight	1200 g
