Brother QL-720NW Quick Setup Guide

32
This section explains how to install BRAdmin Light and P-touch Editor Lite LAN.
Installing the BRAdmin Light
configuration utility
Setting your IP address,
Subnet Mask and Gateway
using BRAdmin Light
6 Installing and using other software
BRAdmin Light (Windows
®
)
1
Click [Network Utility].
This screen is the same
screen as you see when you
insert the CD-ROM.
2
Click [BRAdmin Light] and
follow the onscreen
instructions.
If the Windows
®
Firewall is
enabled on your PC, the
message "Do you wish to add
this application to the list of
exceptions?" appears. Check
your PC environment and
choose [Yes] or [No].
1
Click [Start]-[All
Programs]-[Brother]-
[BRAdmin Light]-
[BRAdmin Light].
BRAdmin Light will search for new
devices automatically.
If you have a DHCP/BOOTP/
RARP server in your network,
you don’t have to do the
following operation. Because
the print server will
automatically obtain its IP
address.
2
Double-click the
unconfigured device.
The default password is
"access."

Brother QL-720NW Specifications

General

Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Maximum printing width	59 mm
Ethernet LAN	Yes
RS-232 ports	1
Connectivity technology	Wired & Wireless
Tape type	DK
Flash memory	6 MB
Number of styles	10
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, EAN128, EAN13, EAN8, ITF-14, MaxiCode, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Number of box types	6
Image formats supported	BMP, GIF, JPG, PNG, TIF
Dimensions (WxDxH)	128 x 236 x 153 mm
Maximum label width	62 mm
Maximum label length	1 m
Product color	Black

Weight and Dimensions

Weight	1200 g
