33
ERROR CODES
The 200 Series Indicator is equipped with software that indicates when an error in the operation
takes place. The following lists the error codes displayed by the 200 Series along with their
meaning. Should you encounter an error code, please refer to this list for the cause.
UnStb (Unstable)
Motion is present when trying to power up, print, zero or perform a push button tare function.
CORRECTIVE ACTION: Wait for a stable weight display (
STABLE
annunciator on) before
performing any of these operations.
-oF- (Overflow)
The indicator is attempting to display a positive number greater than six (6) digits in length or a
negative number of more than five (5) digits.
CORRECTIVE ACTION: Return to Gross Weight mode and review Tare value. May indicate
miscalibration.
OCAP (Over Capacity)
The load on the scale exceeds the scale capacity plus nine (9) divisions.
CORRECTIVE ACTION: Remove the over capacity load from the scale platform. May indicate
miscalibration.
ConFiG (Configuration)
E
2
PROM checksum failure. Indicates improper stored calibration data, calibration is necessary.
CORRECTIVE ACTION: Recalibrate with calibrated test weight.
CALbtn (Calibration Button)
CALbtn will be displayed (until the condition changes), on power-up if the calibration switch is
pressed in by the operator, the calibration access screw is the wrong length and is depressing the
switch, the switch is disconnected from the PC board, or the switch is defective.
CORRECTIVE ACTION: Release the switch. Insure correct screw (#10 x ½ Stainless Steel
fillister head) was installed for the calibration access screw. Referring to Figure No. 6, make
sure calibration switch cable is plugged into P7 on the PC board. Replace calibration switch
assembly. Consult your scale service provider.
Error
An invalid keypad entry was attempted:
A.
PRINT
key pressed with a negative weight.
B.
TARE
key pressed to enter a push button tare value of a negative value.
C.
ENTER
key pressed to enter a tare weight value that exceeds the scale capacity.
D.
ENTER
key pressed to enter a tare weight value that is inconsistent with the scale
division value (i.e. attempt to enter a tare of 123 with scale divisions of 5).
E.
ZERO
key pressed when the gross weight is outside the scale zero weight range.
F.
lb/kg
key pressed to change to kilograms when the kilogram tare weight value exceeds
4 digits in length.
CORRECTIVE ACTION: Determine which of the reasons for the error display is applicable and
take the appropriate corrective action.
ErrAh (Analog Error High)
1. The load cell input is above the range of the indicator.
CORRECTIVE ACTION: Check for improper load cell wiring, excessive load, and for output
of 1 to 40mV.
2. Load cell or circuit failure.
CORRECTIVE ACTION: Consult your scale service provider.
