Carel pCO3 series User Manual

Devices that can be connected to the pCOC
Device
connector J11 connector J19 PCO1004850 PCOS004850 PCO100MDM0 PCO10000F0 PCO10000R0 PCO100CLP0 PCO1000WB0 PCO1000BA0 PCOS00HBB0
Protocol active on the pCO Notes
pCOT - pCOI terminal X Local terminal or pLAN
pGD0 - pGD1 terminal X Local terminal or pLAN With Local terminal the pGD* works in pCOT emulation mode
pGD2 - pGD3 terminal X Local terminal or pLAN
Aria terminal X
pCO in pLAN X pLAN
FCM series controllers X
EVD200 X
EVD400 X
pLAN or CAREL Master or
CAREL Master 5 expansions Can only be activated on one serial port
CAREL Slave devices (RS485) X X X
CAREL Master or CAREL Master: can only be activated on BMS serial.
pCOexp 485 X X X
CAREL Master 5 exp. CAREL Master 5 expansions: can only be activated on pLAN serial
Hydronic fan coil and CANbus X CAREL Master
PlantVisor local X X X
PlantWatch X X X
PCGate X X X
WebGate X X X Can only be activated on one serial port
GATEWAY**0 X X X
LON - Echelon RS485 X Incompatible with protocols
LON - Echelon FTT10 X CAREL Slave PSTN
TREND X GSM
HTTP client X Modbus Slave
BACnet/Ethernet X
BACnet/IP X
BACnet/MSTP (RS485) X
SNMP v1, SNMP v2C X
SNMP v3 X For SNMP v3 special pCOWEB software is used
Modbus supervisor (RTU) X X X Modbus Slave
Incompatible with CAREL Slave, PSTN, GSM
Modbus Slave devices X X X Modbus Master Can only be activated on one serial port
pCOexp Modbus X X X
BenShaw devices X X Modbus Master - Benshaw Maximum of two Benshaw devices
WinLoad local X X X X WinLoad Can only be activated on 1 serial. Incompatible with PSTN & GSM
WinLoad remote, analogue modem X PSTN Incompatible with CAREL Slave and Winload
PlantVisor remote, analogue modem X
WinLoad remote, GSM modem X
PlantVisor remote, GSM modem X GSM Incompatible with CAREL Slave and Winload
Send and receive SMS X
Serial printer X Serial printer
71
serial 0 -
pLAN serial 1 - BMS
