Carrier 50PG20 User Manual

CL-2
-
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -- - - - - - - - - - - - - - - - - - - -
CUT ALONG DOTTED LINE CUT ALONG DOTTED LINE
MODE — CONFIGURATION (cont)
LEGEND
FIOP — Factory-Installed Option
ITEM EXPANSION RANGE DEFAULT ENTRY
CONFIGURATION (cont)
COOL (cont)
SAT Supply Air Temperature
SA.PD SAT Cool Demand (+) Level 0.5 to 10 ^F 1
SA.ND SAT Cool Demand (–) Level –10 to –0.5 ^F –1
SAT.U Minimum SAT Upper Level 35.0 to 65.0 dF 58
SAT.L Minimum SAT Lower Level 35.0 to 65.0 dF 48
SPT Space Temperature
CL.PD SPT Cool Demand (+)
Level
0.5 to 5 ^F 1
CL.ND SPT Cool Demand (–)
Level
–5 to –0.5 ^F –1
C.LAG Cool Thermal Lag Factor 0 to 5 min 1
CIR.A Circuit A
CS.A1 A1 Current Sensing Enable/Disable Disable (1-phase)
Enable (3-phase)
CS.A2 A2 Current Sensing Enable/Disable Disable
A1.FN A Circuit Level 1 Fans 0 to 7 No Humidi-MiZer FIOP
1 (20, 24)
5 (28)
Humidi-MiZer FIOP
1
A2.FN A Circuit Level 2 Fans 0 to 7 No Humidi-MiZer FIOP
3 (20)
2 (24, 28)
Humidi-MiZer FIOP
3 (20)
2 (24, 28)
A3.FN A Circuit Level 3 Fans 0 to 7 No Humidi-MiZer FIOP
3 (20, 24)
7 (28)
Humidi-MiZer FIOP
3
CIR.B Circuit B
CS.B1 B1 Current Sensing Enable/Disable Enable
B1.FN B Circuit Level 1 Fans 0 to 7 No Humidi-MiZer FIOP
4
Humidi-MiZer FIOP
1
B2.FN B Circuit Level 2 Fans 0 to 7 No Humidi-MiZer FIOP
6 (20)
2 (24, 28)
Humidi-MiZer FIOP
3 (20)
2 (24, 28)
B3.FN B Circuit Level 3 Fans 0 to 7 No Humidi-MiZer FIOP
6
Humidi-MiZer FIOP
3
CIR.C Circuit C
CS.C1 C1 Current Sensing Enable/Disable Disable
C1.FN C Circuit Level 1 Fans 0 to 7 0
C2.FN C Circuit Level 2 Fans 0 to 7 0
C3.FN C Circuit Level 3 Fans 0 to 7 0
SST Low Suction Control
SST.O Suction OK Temperature 10 to 50 dF 18
SST.1 Low Suction — Level 1 10 to 50 dF 20
SST.2 Low Suction — Level 2 5 to 50 dF 15
SST.3 Low Suction — Level 3 0 to 50 dF 10
OFC Outdoor Fan Control
OFC.3 OFC3 Enable. CCH
Disable
Ye s / N o Ye s
0.MXP Fan Lev0 Max Pressure 100 to 500 psig 200
1.MXP Fan Lev1 Max Pressure 100 to 500 psig 450
2.MNP Fan Lev2 Min Pressure 100 to 500 psig 200
2.ON Fan Lev2 On Temperature 0 to 100 F no Humidi-MiZer FIOP:
55 (20)
45 (24-28)
Humidi-MiZer FIOP:
68 (20)
61 (24)
61 (28)
2.OFF Fan Lev2 Off Temperature 0 to 100 F no Humidi-MiZer FIOP:
50 (20)
40 (24-28)
Humidi-MiZer FIOP:
57 (20)
57 (24)
57 (28)
2.MXP Fan Lev2 Max Pressure 100 to 500 psig 400
3.MNP Fan Lev3 Min Pressure 100 to 500 psig 250
3.ON Fan Lev3 on Temperature 0 to 100 F no Humidi-MiZer FIOP:
65
Humidi-MiZer FIOP:
88 (20)
68 (24)
68 (28)
