APPENDIX A — LOCAL DISPLAY AND CCN TABLES
MODE — RUN STATUS
ITEM EXPANSION RANGE UNITS
CCN TABLE/
SUB-TABLE
CCN
POINT
WRITE
STATUS
RUN STATUS STATUS DISPLAY
VIEW Auto View of Run Status (VIEW = Display only)
HVAC HVAC Mode Status 1=Disabled
2=Fan Only
3=Cool
4=Heat
OCC Currently Occupied Yes/No
SAT Supply Air Temperature xxx.x dF
ALRM Current Alarms & Alerts xx
TIME Time of Day xx.xx hh.mm
VERS Software Version Numbers VERSIONS
MBB CESR131320-xx-xx
ECB CESR131249-xx-xx
MARQ CESR131171-xx-xx
HRS Component Run Hours STRTHOUR
A1 Compressor A1 Run Hours xxxxx.xx hours HR_A1 Forcible
A2 Compressor A2 Run Hours xxxxx.xx hours HR_A2 Forcible
B1 Compressor B1 Run Hours xxxxx.xx hours HR_B1 Forcible
C1 Compressor C1 Run Hours xxxxx.xx hours HR_C1 Forcible
CCH Crankcase Heat Run Hours xxxxx.xx hours HR_CCH Forcible
IDF Indoor Fan Run Hours xxxxx.xx hours HR_IDF Forcible
OFC.1 Outdoor Fan 1 Run Hours xxxxx.xx hours HR_OFC_1 Forcible
OFC.2 Outdoor Fan 2 Run Hours xxxxx.xx hours HR_OFC_2 Forcible
OFC.3 Outdoor Fan 3 Run Hours xxxxx.xx hours HR_OFC_3 Forcible
HT.1 Heat Stage 1 Run Hours xxxxx.xx hours HR_HTR_1 Forcible
HT.2 Heat Stage 2 Run Hours xxxxx.xx hours HR_HTR_2 Forcible
PE.1 Power Exhaust1 Run Hours xxxxx.xx hours HR_PE_1 Forcible
PE.2 Power Exhaust2 Run Hours xxxxx.xx hours HR_PE_2 Forcible
ALRM Alarm Relay Run Hours xxxxx.xx hours HR_ALM Forcible
CRC Reheat1 Valve Run Hours xxxxx.xx hours HR_CRC Forcible
RH2.A Reheat2 Valve A Run Hrs xxxxx.xx hours HR_RH2_A Forcible
RH2.B Reheat2 Valve BC Run Hrs xxxxx.xx hours HR_RH2_B Forcible
STRT Component Starts
A1 Compressor A1 Starts xxxxxx ST_A1 Forcible
A2 Compressor A2 Starts xxxxxx ST_A2 Forcible
B1 Compressor B1 Starts xxxxxx ST_B1 Forcible
C1 Compressor C1 Starts xxxxxx ST_C1 Forcible
CCH Crankcase Heat Starts xxxxxx ST_CCH Forcible
IDF Indoor Fan Starts xxxxxx ST_IDF Forcible
OFC.1 Outdoor Fan 1 Starts xxxxxx ST_OFC_1 Forcible
OFC.2 Outdoor Fan 2 Starts xxxxxx ST_OFC_2 Forcible
OFC.3 Outdoor Fan 3 Starts xxxxxx ST_OFC_3 Forcible
HT.1 Heat Stage 1 Starts xxxxxx ST_HTR_1 Forcible
HT.2 Heat Stage 2 Starts xxxxxx ST_HTR_2 Forcible
PE.1 Power Exhaust1 Starts xxxxxx ST_PE_1 Forcible
PE.2 Power Exhaust2 Starts xxxxxx ST_PE_2 Forcible
ALRM Alarm Relay Starts xxxxxx ST_ALM Forcible
CRC Reheat1 Valve Starts xxxxxx ST_CRC Forcible
RH2.A Reheat2 Valve A Starts xxxxxx ST_RH2_A Forcible
RH2.B Reheat2 Valve BC Starts xxxxxx ST_RH2_B Forcible
MODE Control Modes MODEDISP
SYS System Mode 1=Disabled
2=Enabled
3=Test
SYS_MODE
HVAC HVAC Mode 1=Off
2=Fan Only
3=Cool
4=Heat
HVACMODE
OCC Currently Occupied Yes/No OCCUPIED Forcible
T.OVR Timed Override in Effect Yes/No MODETOVR
LINK Linkage Active Yes/No MODELINK
C.LOC Circuit OAT Lockout Yes/No COMPLOCK
H.LOC Heat OAT Lockout Yes/No HEATLOCK
E.LOC Econo Cool OAT Lockout Yes/No ECONLOCK
COOL Cooling Status COOLDISP
DMD.C Cooling Demand xxx.x ^F COOL_DMD
AVL.C Available Cooling Stages x AVLCSTGS
REQ.C Requested Cooling Stages x REQCSTGS
IDF Indoor Fan Relay On/Off IDF
CCH Crankcase Heat Relay On/Off CCH
OFC.1 Outdoor Fan 1 Relay On/Off OFC_1
OFC.2 Outdoor Fan 2 Relay On/Off OFC_2
OFC.3 Outdoor Fan 3 Relay On/Off OFC_3
CRC Cool−>Reheat1 Control On/Off CRC
CIR.A Refrigerant Circuit A
CMP.A Compressors A On/Off COMP_A
TG.A Timeguard A xxx sec TIMGD_A
CS.A1 Compressor A1 Feedback On/Off CS_A1
CS.A2 Compressor A2 Feedback On/Off CS_A2
RH2.A Reheat2 Valve A On/Off RH2_A
SST.A Sat. Suction Temp A xxx.x dF SST_A
SSP.A Suction Pressure A xxx.x psig SSP_A
SCT.A Sat. Condenser Temp A xxx.x dF SCT_A
SCP.A Condenser Pressure A xxx.x psig SCP_A
