5 - PHYSICAL AND ELECTRICAL DATA FOR THE UNITS
5.1 - Physical properties: 30RB/30RQ 40R-160R
30RB 040R 045R 050R 055R 060R 070R 080R 090R 100R 120R 140R 160R
Sound levels
Standard unit
Sound power
(1)
dB(A) 81,5 82,0 83,5 83,5 89,0 89,0 89,0 91,5 91,5 92,0 92,0 92,0
Sound pressure at 10 m
(2)
dB(A) 50,0 50,5 52,0 52,0 57,5 57,5 57,5 60,0 60,0 60,5 60,5 60,5
Unit + option 15LS
(3)
Sound power
(1)
dB(A) 78,5 79,0 80,0 80,0 80,0 80,0 80,0 83,0 83,0 83,0 83,0 83,0
Sound pressure at 10 m
(2)
dB(A) 47,0 47,5 48,5 48,5 48,5 48,5 48,5 51,5 51,5 51,5 51,5 51,5
Dimensions - standard unit
Standard unit
Length mm 1061 1061 1061 1061 1061 1061 1061 2258 2258 2258 2258 2258
Width mm 2050 2050 2050 2050 2050 2050 2050 2050 2050 2050 2050 2050
Height mm 1330 1330 1330 1330 1330 1330 1330 1330 1330 1330 1330 1330
Unit height (option 12) mm 1341 1341 1341 1341 1341 1341 1341 1341 1341 1341 1341 1341
Unit height (option 307) mm 1930 1930 1930 1930 1930 1930 1930 1930 1930 1930 1930 1930
Unit height (option 12 + 307) mm 1972 1972 1972 1972 1972 1972 1972 1972 1972 1972 1972 1972
Operating weight
(4)
Standard unit kg 404 405 424 424 430 439 447 665 725 733 848 863
Unit + high pressure single pump option 425 426 444 444 450 460 467 684 745 758 874 888
Unit + high pressure dual pump option 451 453 471 471 477 487 494 711 772 791 906 921
Unit + high pressure single pump and bu󰀨er tank options kg 776 778 796 796 802 812 819 1102 1163 1176 1292 1306
Unit + high pressure dual pump and bu󰀨er tank options kg 803 805 823 823 829 838 846 1129 1190 1209 1324 1339
Compressors Hermetic Scroll 48.3 r/s
Circuit A 2 2 2 2 2 2 2 2 3 3 2 2
Circuit B 2 2
Number of power stages 2 2 2 2 2 2 2 2 3 3 4 4
Refrigerant
(4)
R32/A2L
Circuit A
kg 3,72 3,92 4,15 4,60 4,70 4,87 4,94 7,75 7,95 9,00 4,87 4,94
tCO
2
e 2,5 2,6 2,8 3,1 3,2 3,3 3,3 5,2 5,4 6,1 3,3 3,3
Circuit B
kg 4,87 4,94
tCO
2
e 3,3 3,3
Oil POE
Circuit A l 6,00 6,00 6,60 6,60 6,60 7,20 7,20 7,20 10,80 10,80 7,20 7,20
Circuit B l 7,20 7,20
Capacity control SmartVu
TM
Minimum capacity % 50 50 50 50 50 50 50 50 33 33 25 25
Condenser All-aluminium micro-channel coils (MCHE)
Fans Axial Flying Bird 6 with rotating shroud
Standard unit
Quantity 1 1 1 1 1 1 1 2 2 2 2 2
Maximum total air ow l/s 3882 3802 4058 3900 5484 5452 5414 10568 10512 10974 10904 10827
Maximum rotation speed r/s 12 12 12 12 18 18 18 18 18 18 18 18
Evaporator Direct expansion brazed-plate heat exchanger
Water volume l 3,55 4 4,44 4,44 5,18 6,07 6,96 7,4
8,44 9,92 12,69 14,31
Max. water-side operating pressure without hydraulic
module
kPa 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000
Hydraulic module (option)
Pump, Victaulic screen lter, relief valve, water and air drain valve, pressure
sensors, expansion tank (option)
Pump
Centrifugal pump, monocell, 48.3 r/s, low- or high-pressure (as required),
single or dual (as required)
Expansion tank volume l 12 12 12 12 12 12 12 35 35 35 35 35
Max. water-side operating pressure with hydraulic module kPa 400 400 400 400 400 400 400 400 400 400 400 400
Hydraulic connections with/without hydraulic module Victaulic
®
type
Connections inches 2 2 2 2 2 2 2 2 2 2 2 2
External diameter mm 60,3 60,3 60,3 60,3 60,3 60,3 60,3 60,3 60,3 60,3 60,3 60,3
Casing paint colour Colour code RAL 7035
(1) In dB ref=10
-12
W, (A) weighting. Declared dual-number noise emission values in accordance with ISO 4871 with an associated uncertainty of +/-3dB(A). Measured in
accordance with ISO 9614-1 and certied by Eurovent.
(2) In dB ref 20 µPa, (A) weighting. Declared dual-number noise emission values in accordance with ISO 4871 with an associated uncertainty of +/-3dB(A). For information,
calculated from the sound power level Lw(A).
(3) Values are guidelines only. Refer to the unit name plate.
12
