Carrier Aquasnap 30RB 160R User Manual

13.4 - Tightening of the electrical connections
Component Description Value (N.m)
Soldered screw (PE) customer connection
M8 PE 14,5
Screw on terminal inlet board
Terminal 56.395.0055.0 X100 10
Terminal 56.398.0055.0 14
Terminal screw, main circuit breaker
Disconnect switch - MG 28908 QS_ 8
Disconnect switch - MG 28910 8
Disconnect switch - MG 28912 8
Disconnect switch - MG 28949 8
Cage terminal screw, compressor contactor
LC1D18B7 1.7 control section 1.7 power section
LC1D25B7 1.7 control section 2.5 power section
LC1D32B7 1.7 control section 2.5 power section
LC1D40AB7 1.7 control section 5 power section (1 to 25 mm
2
cable)
LC1D50AB7 1.7 control section 5 power section (1 to 25 mm
2
cable)
Cage terminal screw, compressor fuse holder
Fuse holder DF223C FU* 4
Fuse holder DF143C 3,5
Cage terminal screw, compressor soft starter
Soft Starter 3RW4028-1BB04 GS* 1.2 control section 4.5 power section
Soft Starter 3RW4036-1BB04 1.2 control section 4.5 power section
Soft Starter ATS01N232QN399
Starter terminals 1L1, 2T1, 3L2, 4T2, 5L3, 6T3=
1.9 to 2.5
Starter terminals R1A, R1C, COM, LI, LI2, L01,
BOOST= 0.5
Tunnel terminal screw, control power transformer
Transformer - 40958E TC 0,6
Transformer - 40959E
Transformer - 40888E
Transformer - 40894E
Compressor earth terminal in the power wiring control box
M6 Gnd 5,5
Compressor earth connection
M8 Gnd 2,83
Case terminal screw, circuit breaker (fan, pump)
Circuit breaker A9F94204 QM* 2
Circuit breaker A9F94206 2
Circuit breaker GV2DP120B7 1.7 contactor side 1.7 circuit breaker side
Circuit breaker GV2DP132B7 1.7 contactor side 1.7 circuit breaker side
Circuit breaker GV2ME06 1,7
Circuit breaker GV2ME07 1,7
Circuit breaker GV2ME08 1,7
Circuit breaker GV2ME10 1,7
Circuit breaker GV2ME14 1,7
Circuit breaker GV2RT07 1,7
Circuit breaker GV2RT08 1,7
Circuit breaker GV2RT10 1,7
Tunnel terminal screw, contactor (fan, pump)
LC1K0610B7 KM* 1,3
LC1K09004B7 1,3
LC1K0901B7 1,3
LC1K0910B7 1,3
LA1KN20 1,3
LA1SK02 0,8
LADN11 1,7
Cage terminal screw, EMC lter (fan, pump)
EMC lter VW3A31404
ZGS*
1,8
EMC lter VW3A31406 1,8
Cage terminal screw, control panel fan
NSYCCOTHC
EV*
0,5
NSYCCOTHO 0,5
Cage terminal screw, control relay
Relay CA2SK20B7 K* 0,8
13 - STANDARD MAINTENANCE
47
