APPENDIX A
Compressor Must Trip Amps (Determined by CPM Modules)
COMPRESSOR MUST TRIP AMPS
2-COMPRESSOR UNITS
Unit Size Unit Voltage
Compressor A1, B1
Must Trip Amps
30GX080
575-3-60 98, 82
380-3-60 148,124
208/230-3-60 270,226
460-3-60 122,102
230-3-50 256,212
380/415-3-50 156,128
30GX090
575-3-60 120, 82
380-3-60 180,124
208/230-3-60 328,226
460-3-60 148,102
230-3-50 310,212
380/415-3-50 188,128
30GX105
230-3-50 344,238
380/415-3-50 208,144
30GX106
575-3-60 134, 92
380-3-60 202,140
208/230-3-60 368,254
460-3-60 168,114
230-3-50 344,238
380/415-3-50 208,144
30GX115
575-3-60 162, 92
380-3-60 246,140
208/230-3-60 448,254
460-3-60 204,114
230-3-50 418,238
380/415-3-50 254,144
30GX125
575-3-60 162,110
380-3-60 246,168
208/230-3-60 448,306
460-3-60 204,138
230-3-50 418,288
380/415-3-50 254,174
30GX136
575-3-60 162,134
380-3-60 246,202
208/230-3-60 448,368
460-3-60 204,168
230-3-50 418,344
380/415-3-50 254,208
30GX150
230-3-50 344,520
380/415-3-50 208,314
30GX151
575-3-60 198,134
380-3-60 300,202
208/230-3-60 546,368
460-3-60 240,168
30GX160
230-3-50 418,520
380/415-3-50 254,314
30GX161
575-3-60 198,162
380-3-60 300,246
208/230-3-60 546,448
460-3-60 248,204
230-3-50 520,418
380/415-3-50 314,254
30GX175
230-3-50 520,520
380/415-3-50 314,314
30GX176
575-3-60 198,198
380-3-60 300,300
208/230-3-60 546,546
460-3-60 248,248
30HXA076
575-3-60 82, 82
380-3-60 124,124
346-3-50 140,140
208/230-3-60 226,226
460-3-60 102,102
230-3-50 212,212
380/415-3-50 128,128
30HXA086
575-3-60 98, 82
380-3-60 148,124
346-3-50 170,140
208/230-3-60 270,226
460-3-60 122,102
230-3-50 256,212
380/415-3-50 156,128
COMPRESSOR MUST TRIP AMPS
2-COMPRESSOR UNITS
Unit Size Unit Voltage
Compressor A1, B1
Must Trip Amps
30HXA096
575-3-60 120, 82
380-3-60 180,124
346-3-50 206,140
208/230-3-60 328,226
460-3-60 148,102
230-3-50 310,212
380/415-3-50 188,128
30HXA106
575-3-60 144, 82
380-3-60 218,124
346-3-50 250,140
208/230-3-60 400,226
460-3-60 180,102
230-3-50 376,212
380/415-3-50 228,128
30HXA116
575-3-60 144, 98
380-3-60 218,148
346-3-50 250,170
208/230-3-60 400,270
460-3-60 180,122
230-3-50 376,256
380/415-3-50 228,156
30HXA126
575-3-60 144,120
380-3-60 218,180
346-3-50 250,206
208/230-3-60 400,328
460-3-60 180,148
230-3-50 376,310
380/415-3-50 228,188
30HXA136
575-3-60 176,120
380-3-60 266,180
346-3-50 306,206
208/230-3-60 486,328
460-3-60 220,148
230-3-50 462,310
380/415-3-50 280,188
30HXA146
575-3-60 176,144
380-3-60 266,218
346-3-50 306,250
208/230-3-60 486,400
460-3-60 220,180
230-3-50 462,376
380/415-3-50 280,228
30HXA161
575-3-60 198,134
380-3-60 300,202
346-3-50 344,228
208/230-3-60 546,368
460-3-60 248,168
230-3-50 520,344
380/415-3-50 314,208
30HXA171
575-3-60 162,198
380-3-60 246,300
346-3-50 278,344
208/230-3-60 448,546
460-3-60 204,248
230-3-50 418,520
380/415-3-50 254,314
30HXA186
575-3-60 198,198
380-3-60 300,300
346-3-50 344,344
208/230-3-60 546,546
460-3-60 248,248
230-3-50 520,520
380/415-3-50 314,314
74
