6-20T -309
Table 6-3 Crack, Chip & Hole Repair Kit
ITEM DESCRIPTION PART NUMBER Qty
1 Crack Repair Kit -- Includes 76--00724--00SV 1
2 Fiberglass Patch Kit (Loctite FK --98 or 80265)... 76--00724--00Z 10
3 Sikaflex 221 Adhesive Sealant (Sikaflex 232--361)... 02--00067--02Z 10
4 Instruction Sheet... 98--02339--00 10
Table 6-4 Insert Repair Kit
ITEM DESCRIPTION PART NUMBER Qty
1 Insert Repair Kit -- Includes 76--50084--00 1
2 Insert - 17.53 x 9.91 mm (..690 x .390 in) 1/4--20 Threads... 34--06231--01 10
3 Insert - 15.88 x 6.35 mm (.625 x .250 in) 10-24 Threads... 34--06231--03 10
4 Insert - 25.15 x 7.54 mm (.990 x .297 in) 10-24 Threads... 34--06231--04 10
5 Insert - 10.16 x 9.53 mm (.400 x .375 in) 10-24 Threads... 34--06231--05 10
6 Insert - 12.7 x 9.91 mm (.5 x .390 in) 1/4--20 Threads... 34--06231--06 10
7 Insert - 9.53 x 6.76 mm (. 375 x .266 in) 10-24 Threads... 34--06231--07 10
8 Durabond Epoxy E20--HP (Loctite 29314)... 02--0082--00 1
9 Static Mixing Tube (Loctite 983440)... 07--00390--00 1
10 Instruction Sheet... 98--02338--00 1
Note: Insert repair procedures require use of an Application Gun, Carrier part number 07--00391--00
Table 6-5 Drill Information
Item
Insert part number Drill size and depth
1 34- 06231- 01 10.3 mm x 17.8 mm deep (.404 in. x .700 in. deep)
2 34- 06231- 03 6.8 mm x 16.3 mm deep (.266 in. x .640 in. deep)
3 34- 06231- 04 7.9 mm x 25.4 m m deep (.3125 in. x 1.0 in. deep)
4 34- 06231- 05 6.9 mm (.270 in.) Drill completely through.
5 34- 06231- 06 10.3 mm (.404 in.) Drill completely through.
6 34- 06231- 07 6.8 mm (.266 in.) Drill completely through.
