Casio ALGEBRA FX 2.0 Plus User Manual

20010101
Example 2 To input and execute 1238 × ABC16, when the default number system is
decimal or hexadecimal
u3(SET UP)2(Dec)i
A1(d~o)e(o)bcd*
1(d~o)c(h)ABC*
1
w
3(DISP)c(Hex)w
kk
kk
k Negative Values and Bitwise Operations
Press 2(LOGIC) to display a menu of negation and bitwise operators.
•{Neg} ... {negation}*
2
•{Not}/{and}/{or}/{xor}/{xnor} ... {NOT}*
3
/{AND}/{OR}/{XOR}/{XNOR}*
4
u Negative Values
Example To determine the negative of 1100102
u3(SET UP)4(Bin)i
A2(LOGIC)b(Neg)
bbaabaw
uBitwise Operations
Example 1 To input and execute “12016 and AD16”
u3(SET UP)3(Hex)i
Abca2(LOGIC)
d(and)AD*
1
w
2-7-4
Binary, Octal, Decimal, and Hexadecimal Calculations with Integers
*
1
See page 2-7-1.
*
2
two’s complement
*
3
one’s complement (bitwise complement)
20011101
*
4
bitwise AND, bitwise OR, bitwise XOR,
bitwise XNOR

Casio ALGEBRA FX 2.0 Plus Specifications

General

Type	Scientific
Cover	No
Form factor	Pocket
Control type	Buttons
Product color	Black
Digits	12 digits
Display type	Dot-matrix
Backlight color	Green
Backlight display	Yes
Display resolution	128 x 64 pixels
Display number of lines	8 lines
Display number of characters	21
RAM capacity	0.75 MB
ROM capacity	0.1406 MB
Storage media type	-
Battery type	CR2032, AAA
Power source	Battery
Number of batteries supported	5

Weight and Dimensions

Depth	178 mm
Width	82 mm
Height	19.5 mm
Weight	213 g
