Casio ALGEBRA FX 2.0 Plus User Manual

19990401
5-2 Controlling What Appears on a Graph Screen
kk
kk
k V-Window (View Window) Settings
Use the View Window to specify the range of the x- and y-axes, and to set the spacing
between the increments on each axis. You should always set the V-Window parameters you
want to use before graphing.
u To make V-Window settings
1. From the Main Menu, enter the GRPH
•
TBL Mode.
2. Press !K(V-Window) to display the V-Window setting screen.
Rectangular coordinate parameter
Xmin … Minimum x-axis value
Xmax … Maximum x-axis value
Xscale … Spacing of x-axis increments
Xdot … Value that corresponds to one x-axis dot
Ymin … Minimum y-axis value
Ymax … Maximum y-axis value
Yscale … Spacing of y-axis increments
Polar coordinate parameter
T θ min ... T, θ minimum values
T θ max ... T, θ maximum values
T θ ptch ... T, θ pitch
3. Press c to move the highlighting and input an appropriate value for each parameter,
pressing w after each.
• {INIT}/{TRIG}/{STD} … V-Window {initial settings}/{initial settings using specified
angle unit}/{standardized settings}
•{STO}/{RCL} … V-Window setting {store}/{recall}
After settings are the way you want them, press i or !i(QUIT) to exit the V-Window
setting screen.*
1
5-2-1
Controlling What Appears on a Graph Screen
*
1
Pressing w without inputting anything while k
is displayed exits the View Window setting
screen.
20011101

Casio ALGEBRA FX 2.0 Plus Specifications

General

Type	Scientific
Cover	No
Form factor	Pocket
Control type	Buttons
Product color	Black
Digits	12 digits
Display type	Dot-matrix
Backlight color	Green
Backlight display	Yes
Display resolution	128 x 64 pixels
Display number of lines	8 lines
Display number of characters	21
RAM capacity	0.75 MB
ROM capacity	0.1406 MB
Storage media type	-
Battery type	CR2032, AAA
Power source	Battery
Number of batteries supported	5

Weight and Dimensions

Depth	178 mm
Width	82 mm
Height	19.5 mm
Weight	213 g
