The numbers in parentheses indicate the pages where each item is explained.
General Guide
42135
67
[ ]
[
SET
]
[ ]
[ ]
[ ]
8 9bkbl
bo bmbn
1
Zoom controller
(pages 24, 35, 66, 66)
2
Shutter button (page 24)
3
Flash (page 32)
4
[ON/OFF] (Power)
(page 21)
5
Front lamp (page 34)
6
Lens
7
Microphone
(pages 39, 74)
8
Back lamp
(pages 14, 15, 32)
9
[0] (Movie) button
(page 38)
bk
Strap hole (page 22)
bl
[p] (PLAY) button
(pages 21, 27)
bm
[SET] button
([8][2][4][6])
(pages 11, 28, 31, 32,
47)
bn
[MENU] button
(page 47)
bo
Monitor screen
(pages 9, 11)
BackFront
Bottom
bsbt brcl ck
bp
bq
bp
[USB/AV] port (pages 13, 14, 67)
bq
Memory card slot (page 19)
br
Memory card slot/connector cover
bs
Battery cover
bt
Battery slot (page 109)
ck
Speaker
cl
Tripod hole
Use this hole when attaching to a tripod.
