Important!
• When printing, the tape repeatedly feeds forward and back while the print operation is being per-
formed. The tape is cut automatically after the print operation is complete. Never pull on the tape or
turn off QG-100 power while a print operation is being performed.
• The POWER indicator color becomes orange while printing is being performed, and changes back to
green when printing is completed.
• Pressing PRINT causes the POWER indicator to start flashing orange, indicating that data is being
received from the digital camera. It may take a bit of time before actual printing begins.
• Start of a print operation may cause a little bit of blank tape to feed from the printer.
• Never open the printer's cover while a print operation is in progress.
• Printing may stop momentarily while you are outputting a series of prints or after you have used the
QG-100 continually for a long time. This is a normal operation that the QG-100 performs to protect
against overheating, and does not indicate malfunction. Normal printing should resume automatically.
• The color of an image printed on the printer may vary a little from the color of the actual item.
7-1. SENSOR POSITION
See to 11-1. EXPLODED VIEW (Z568-1 ASS'Y & COMPONENTS) ( 30 page).
7-2. PRINTING SPECIFICATION
• Printing method — thermal printing
• Printing head — 384 dots
• Resolution — 200 dpi (dots per inch)
• Gradation number — 64 (gradation)
• Tape cartridge — 18, 36 & 46 mm width tape
• Printing size — Standard printing: 3 varieties/18 mm × 6, 36 mm × 1, 46 mm × 1
Multi-image printing: 2 varieties/36 mm × 2, 46 mm × 4
• Printing time (Standard printing) — 18 mm tape ... about 4 minutes 15 sec. (6 images printing)
36 mm tape ... about 2 minutes 15 sec.
46 mm tape ... about 2 minutes 45 sec.
● Tape types and sizes when connecting to a QV Digital Camera
Print size is set automatically according to the width of tape loaded.
18 tape provides 30 prints.
36 tape provides 60 prints.
46 tape provides 50 prints.
Store tapes in their original plastic bags in an area where they will not be subjected to high humidity.
Be sure to use only tape cartridges designed specially for use with the QG-100.
Standard Print Size Multi-image Size
(Number of Prints) (Number of Prints)
QR-18CR 18 mm (
11
/16") 16.0 × 21.5 (6) 16.0 × 21.5 (6)
QR-36CR 36 mm (1
3
/8") 27.5 × 37.0 (1) 16.0 × 21.5 (2)
QR-46CR 46 mm (1
13
/16") 41.25 × 55.5 (1) 16.0 × 21.5 (4)
Tape Width
