PARTS LIST 10-7: CASSETTE CASE ASS'Y
N Item Code No. Parts Name Specification Version Q R
CASSETTE CASE ASS'Y
N1
6417 7760 Cassette case Z568 A140425-1 QG-100 Common
1
X
2
6415 5380 Switch key Z561 A440618-1 QG-100 Common
3
C
N3
6418 7070 Z568-2 ass'y A240668*1 QG-100 Common
1
C
N4
6418 6970 Z568-S3 ass'y A341188A*1 QG-100 Common
1
C
Z568-2 ASS'Y
N IC1
2105 4158 Linear IC TA75S393F-TE85L QG-100 Common
1
B
N Q1~4
2259 2324 Digital transistor 2SC4617-TR QG-100 Common
4
B
Q7
2251 0609 Chip transistor 2SB1132R-T101 QG-100 Common
1
B
D4
2390 1372 Chip diode DA204U-T106 QG-100 Common
1
C
5
3110 6035 Switch SW-74 QG-100 Common
1
C
6
3110 6028 Switch SW-163 QG-100 Common
1
C
7
3501 6384 Connector B6B-PH-K-S QG-100 Common
1
C
8
3501 3724 Connector B2B-ZR QG-100 Common
1
C
N CN201
3502 1634 FFC connector 086210026010800 QG-100 Common
1
C
CN202
3501 7546 Connector B5B-ZR-SM3-TF QG-100 Common
1
C
CN204
3501 9401 Connector B3B-ZR-SM3-TF QG-100 Common
1
C
CN205
3501 7553 Connector B6B-ZR-SM3-TF QG-100 Common
1
C
N9
3725 2800 FFC joiner B-Z568 A441811-1 QG-100 Common
1
C
The follwing electronic parts will be not supplied by CASIO.
C10
Chip capacitor GRM39B102K50PT QG-100 Common
1
C12
Chip capacitor GRM39F104Z25PT QG-100 Common
1
C13,14
Chip capacitor GRM40F105Z16PT QG-100 Common
2
R1,5,6,12,23
Chip resister MCR03EZHJ473 QG-100 Common
5
R2
Chip resister MCR03EZHJ333 QG-100 Common
1
R3,9,10,13,14
Chip resister MCR03EZHJ391 QG-100 Common
5
R7
Resistor ERG-2SJ180 QG-100 Common
1
R8,18
Chip resister MCR03EZHF9101 QG-100 Common
2
R11
Chip resister MCR03EZHJ183 QG-100 Common
1
R15
Chip resister MCR03EZHJ104 QG-100 Common
1
R20,21
Chip resister MCR03EZHJ105 QG-100 Common
2
R22
Chip resister MCR03EZHJ182 QG-100 Common
1
R30
Chip resister MCR03EZHJ106 QG-100 Common
1
Z568-S3 ASS'Y
N10
6417 7530 Wire sub ass'y C A441809*1 QG-100 Common
1
X
11
3122 3199 Photosensitive device ON2171.CS QG-100 Common
2
C
Parts prices will be informed separately by Parts Price List.
Notes: N – New parts R – A: Essential
Q – Quantity used per unit B: Stock recommended
R – Rank C: Others
X: No stock recommended
— 45 —
