Casio QG-100 User Manual

PARTS LIST 10-3: CHASSIS UNIT
N Item Code No. Parts Name Specification Version Q R
CHASSIS UNIT
N 1 6417 8260 Gear E-Z568 A441767-1 QG-100 Common
1
X
N 2 6417 8240 HS. shaft Z568 A441756-1 QG-100 Common
1
X
N 3 6417 7990 Head plate Z568 A341230-1 QG-100 Common
1
X
N 4 6417 7790 Tape holder Z568 A240692-1 QG-100 Common
1
X
N 5 6417 8091 H. stopper B-Z568 A441685A-1 QG-100 Common
1
X
N 6 6417 8000 Cut washer A-Z568 A412353-7 QG-100 Common
1
X
N7
6417 7871 Upper chassis Z568 A341092A-1 QG-100 Common
1
X
N8
6417 8330 Platen spacer Z568 A441783-1 QG-100 Common
1
X
9
6400 9740 Cut washer A-L240 A412353-1 QG-100 Common
1
X
10
6410 7120 Spring T-L263 C413536-1 QG-100 Common
1
X
N 11 6417 7890 Gear D-Z568 A341105-1 QG-100 Common
1
X
N12
6417 7970 HS. cover Z568 A341209-1 QG-100 Common
1
X
N13
6417 8420 HS. spring Z568 A441874-1 QG-100 Common
1
X
N14
6418 6940 Chassis ass'y A140410A*1 QG-100 Common
1
C
N15
6418 6950 Head holder ass'y A240623A*1 QG-100 Common
1
B
N16
6418 6960 Platen ass'y A240624A*1 QG-100 Common
1
C
Parts prices will be informed separately by Parts Price List.
Notes: N – New parts R – A: Essential
Q – Quantity used per unit B: Stock recommended
R – Rank C: Others
X: No stock recommended
— 34 —
