PARTS LIST 10-4: CHASSIS ASS'Y
N Item Code No. Parts Name Specification Version Q R
CHASSIS ASS'Y
1
6415 5340 Gear F-Z561 A440606-1 QG-100 Common 1 X
N2
6417 8060 Gear A-Z568 A441682-1 QG-100 Common 2 X
N3
6417 8070 Gear B-Z568 A441683-1 QG-100 Common 1 X
N4
6417 8080 Gear C-Z568 A441684-1 QG-100 Common 1 X
N5
6417 8390 Gear F-Z568 A441862-1 QG-100 Common 1 X
N6
6417 7800 Upper cam Z568 A240693-1 QG-100 Common 1 X
N7
6417 7810 Lower cam Z568 A240694-1 QG-100 Common 1 X
N8
6417 7930 Scissors gear C-Z568 A341144-1 QG-100 Common 1 X
N9
6417 7850 Return gear Z568 A341073-1 QG-100 Common 1 X
N10
6417 7880 Clutch gear Z568 A341099-1 QG-100 Common 1 X
N11
6417 8370 Sensor label Z568 A441802-1 QG-100 Common 1 X
N12
6417 7980 Gear G-Z568 A341227-1 QG-100 Common 1 X
N13
6416 7540 Cut washer Z561 A441520-1 QG-100 Common 1 X
14
6400 9750 Cut washer B-L240 A412353-2 QG-100 Common 7 X
15
6405 2550 Cut washer D-L240 A412353-4 QG-100 Common 1 X
16
6415 5370 Brake spring Z561 A440615-1 QG-100 Common 1 X
17
6415 5230 Winder top Z561 A340675-1 QG-100 Common 1 X
N18
6416 5900 Clutch felt B-Z592 A441415-1 QG-100 Common 1 X
19
6415 5140 Clutch plate Z561 A340400-1 QG-100 Common 1 X
N20
6417 8490 Clutch spring Z568 A441949-1 QG-100 Common 1 X
21
6400 9720 Spring washer L240 A412351-1 QG-100 Common 1 X
22
3222 0154 Stepping motor SMB35-4857-A QG-100 Common 1 C
23
6415 5180 Gear A-Z561 A340412-1 QG-100 Common 1 X
N24
6417 7330 Chassis sub ass'y A240605*1 QG-100 Common 1 C
N25
6418 7110 Gear arm ass'y A441690*1 QG-100 Common 1 C
N
26
6418 6980 Z568-S2 ass'y A341187B*1 QG-100 Common 1 C
Z568-S2 ASS'Y
N27
6417 7520 Wire sub ass'y B A441808*1 QG-100 Common 1 X
N28
3122 3381 Photosensitive device ON2170-R(LF) QG-100 Common 2 C
Parts prices will be informed separately by Parts Price List.
Notes: N – New parts R – A: Essential
Q – Quantity used per unit B: Stock recommended
R – Rank C: Others
X: No stock recommended
— 37 —
To Next Page
