PARTS LIST 10-1: Z568-1 ASS'Y, COMPONENT & OTHERS
N Item Code No. Parts Name Specification Version Q R
Z568-1 ASS'Y
N LSI1 2012 2751 LSI MN1020004-1 QG-100 Common
1
B
N LSI2 2012 1442 LSI MN7A076KYL QG-100 Common
1
B
N LSI3 2012 5498 LSI LC371100SM-E59 QG-100 Common
1
B
N LSI4 2012 4130 LSI TC55257DFL-70L QG-100 Common
1
B
LSI5,6 2012 1449 LSI TC518128CFL-80 QG-100 Common
2
B
IC1 2105 2667 CMOS IC RH5VL45AA QG-100 Common
1
B
IC2 2105 1547 CMOS IC TC7S00F-TE85R QG-100 Common
1
B
N IC3 2113 0329 Bipolar IC MC1413DTR2 QG-100 Common
1
B
N IC4 2113 0322 Bipolar IC BA6885FS-E2 QG-100 Common
1
B
Q1 2259 2282 Digital transistor DTC114YE-TR QG-100 Common
1
B
N Q2~4 2259 2576 Chip digital transistor DTA144EE-TR QG-100 Common
3
B
N X1 2590 2415 Ceramic oscillator CSTCS24.00MX040-TC QG-100 Common
1
C
N EMI1 3045 0140 Chip ferrite bead BLM11P300SPT QG-100 Common
1
C
N EMI6,9,11, 3045 0126 Chip ferrite bead BLM11A601SPT QG-100 Common
9
C
EMI20~25
N EMI12~15 3045 0175 Chip ferrite bead BLM11B141SPT QG-100 Common
4
C
N EMI16,17 3045 0196 Chip ferrite bead N1608ZA800T01 QG-100 Common
2
C
N CN1 3502 1627 FFC connector 046214026010800 QG-100 Common
1
C
N CN2 3502 1613 FFC connector 006208513210000 QG-100 Common
1
C
CN3 3501 9758 Connector B11B-PH-SM3-TB QG-100 Common
1
C
N CN4 3502 1620 FFC connector 006208515210000 QG-100 Common
1
C
N 1 6417 7940 Shield case A-Z568 A341150-1 QG-100 Common
1
X
N 2 6417 7950 Shield case B-Z568 A341151-1 QG-100 Common
2
X
N 3 6418 6420 Tape F-Z568 A442209-1 QG-100 Common
2
X
The following electronic parts will be not supplied from CASIO.
C1 Chip capacitor MCH185A431JK QG-100 Common
1
C2,C4~6, Chip capacitor GRM39F104Z25PT QG-100 Common
12
C9,13,18,
C20,21,28,
C29,34
C3,7,8,12, Chip capacitor GRM39B102K50PT QG-100 Common
10
C14,16,17,
C23~25
C10 Chip capacitor GRM40F105Z16PT QG-100 Common
1
C11,30,31 Chip capacitor GRM39F103Z50PT QG-100 Common
3
C15 Tantalum capacitor ECST1AY685R QG-100 Common
1
C19,32,33 Chip electrolytic capacitor ECEV1VA100P QG-100 Common
3
C26,27 Chip capacitor GRM39CH240J50PT QG-100 Common
2
C43 Chip electrolytic capacitor ECEV0JA470SP QG-100 Common
1
R3 Chip resistor MCR03EZHF2702 QG-100 Common
1
R7~9 Chip resistor MCR03EZHJ331 QG-100 Common
3
R10~12, Chip resistor MCR03EZHJ473 QG-100 Common
14
R17~20,
R23, R25~28,
R31,42
R13 Chip resistor MCR03EZHJ333 QG-100 Common
1
R14 Chip resistor MCR03EZHJ221 QG-100 Common
1
R15 Chip resistor MCR03EZHJ272 QG-100 Common
1
Notes: N – New parts R – A: Essential
Q – Quantity used per unit B: Stock recommended
R – Rank C: Others
X: No stock recommended
— 27 —
