PARTS LIST 10-8: MOTOR CHASSIS ASS'Y
N Item Code No. Parts Name Specification Version Q R
MOTOR CHASSIS ASS'Y
N1
6417 8040 Scissors gear A-Z568 A441680-1 QG-100 Common
1
X
N2
6417 8200 Scissors gear B-Z568 A441698-1 QG-100 Common
1
X
3
6400 9750 Cut washer B-L240 A412353-2 QG-100 Common
1
X
N4
6417 7400 M. chassis sub ass'y A341070*1 QG-100 Common
1
X
N5
6418 7090 Motor ass'y A441848A*1 QG-100 Common
1
C
MOTOR ASS'Y
N6
6417 7540 Wire sub ass'y D A441812*1 QG-100 Common
1
X
N7
6417 8030 Worm gear Z568 A441679-1 QG-100 Common
1
X
N8
3222 0175 DC motor NF183G QG-100 Common
1
C
Parts prices will be informed separately by Parts Price List.
Notes: N – New parts R – A: Essential
Q – Quantity used per unit B: Stock recommended
R – Rank C: Others
X: No stock recommended
