Fork carriage
All bushings and axles used on the fork carriage have a new design. This chapter
describes these parts together with the forks and fork wheels.
Forks and support arms
The fork thickness has been standardised to 60 mm on all models, except the S214
and S214L that have 70 mm thick forks to manage heavier loads. The fork width is
180 mm. A wide range of fork congurations with different lengths and widths over
forks is available as indicated in the table below. Please note that fork conguration
affects residual capacity. For more information, please refer to the capacity charts
under Technical information. An FEM 2A fork carriage is used on the S version.
Only the D version has different support arm lengths. This truck is adapted for
holding loads also on the support arms. The support arm length always depends on
the selected fork length.
The support arms for S212S comes in ve widths, 900, 1070, 1220, 1245 or 1300
mm. They are not adjustable.
Feature
Possible fork congurations in terms of length and width over forks (fork length *
WOF , Width Over Forks in mm):
Model Fork conguration, stackers, mm
S208L
Fork length 1150/1200
Width over forks 536/550/570/685
S210
Fork length 1000/1150 and 1100 -1800 in steps of 100 mm
Width over forks 536/570/685
S212
Fork length 1000/1150 and 1100-1800 in steps of 100 mm
Width over forks 536/570/685
S212L
Fork length 1000/1150
Width over forks 536/570
S212S
Fork length 1150/1250
Width over forks 252-800
S214
Fork length 1000/1150 and 1100 -1800 in steps of 100 mm
Width over forks 536/570/685
S214L
Fork length 1000/1150
Width over forks 536/570
S220D
Fork length 1150/1200
Width over forks 536/570
