CESAB S208L User Manual

Technical information
Product guide – CESAB S200
78
Model S212S S208L
Mast Triplex Mono
Lh (mm) 4455 1580
Battery compartment M L
Drive wheel load, kg 728 757 747
Support arm load, kg 1620 1652 1807
Castor wheel load, kg 150
Machine weight without battery and load 928 939 492
Drive wheel pressure, kg/mm
2
0,32 0,32 0,32
Castor wheel pressure, kg/mm
2
0,19
Support arm wheel pressure, boggie (4), kg/mm
2
0,43 0,43 0,45
Support arm wheel, single (2), kg/mm
2
0,64 0,64 0,68
Fork dimensions
Fixed support arms, 570x 1000-1150
Elevating support arms, 570x 1150
Model S210 S210
Mast Simplex Duplex Tele
Lh (mm) 1700 3300
Battery compartment S M L S M L
L
2
measurement, mm 676 733 783 683 740 790
x-measurement, mm 664 664 664 657 657 657
Drive wheel - front border 150 150 150 150 150 150
Wheel base y, mm 1190 1247 1297 1190 1247 1297
Axle - support arm tip, mm 169 169 169 169 169 169
Back of forks - support arm tip, mm 833 833 833 826 826 826
Model S212 S212 S212
Mast Simplex Dx Tele Dx Free lift
Lh (mm) 1700 4150 4150
Battery compartment M L
1)
M L
1)
M L
1)
L
2
measurement, mm 772 822 750 800 758 808
x-measurement, mm 625 625 647 647 639 639
Drive wheel - front border 150 150 150 150 150 150
Wheel base y, mm 1247 1297 1247 1297 1247 1297
Axle - support arm tip, mm 169 169 169 169 169 169
Back of forks - support arm tip, mm 794 794 816 816 808 808
1) Sideways battery change
●
●
