CESAB S208L User Manual

Technical information
Product guide – CESAB S200
75
Wheel Pressure
Fixed support arms, 570x 1000-1150
Elevating support arms, 570x 1150
Wheel pressure for rated load
Model S210 S210
Mast Simplex Duplex Tele
Lh (mm) 1700 3300
Battery compartment S M L S M L
Drive wheel load, kg 350 350 350 350 350 350
Support arm load, kg 1127 1151 1176 1165 1192 1219
Castor wheel load, kg 245 287 323 301 341 374
Machine weight without battery and load 557 568 580 651 663 674
Drive wheel pressure, kg/mm
2
0,20 0,20 0,20 0,20 0,20 0,20
Castor wheel pressure, kg/mm
2
0,25 0,27 0,29 0,28 0,30 0,31
Support arm wheel pressure, boggie (4), kg/mm
2
0,34 0,35 0,35 0,35 0,36 0,36
Support arm wheel, single (2), kg/mm
2
0,43 0,43 0,44 0,44 0,45 0,45
Model S212 S212 S212
Mast Simplex Dx Tele Dx Free lift
Lh (mm) 1700 4150 4150
Battery compartment M L
1)
M L
1)
M L
1)
Drive wheel load, kg 400 400 400 400 400 400
Support arm load, kg 1345 1371 1417 1447 1436 1465
Castor wheel load, kg 267 302 336 368 342 373
Machine weight without battery and load 593 604 733 745 759 769
Drive wheel pressure, kg/mm
2
0,22 0,22 0,22 0,22 0,22 0,22
Castor wheel pressure, kg/mm
2
0,26 0,28 0,30 0,32 0,30 0,32
Support arm wheel pressure, boggie (4), kg/mm
2
0,38 0,39 0,40 0,40 0,40 0,40
Support arm wheel, single (2), kg/mm
2
0,57 0,58 0,59 0,60 0,59 0,60
1) Sideways battery change
Model S212 S212
Mast Dx Tele Openview. Triplex
Lh (mm) 4150 4500
Battery compartment M L
1)
M L
1)
Drive wheel load, kg 400 400 400 400
Support arm load, kg 1436 1465 1465 1504
Castor wheel load, kg 342 373 348 379
Machine weight without battery and load 757 769 802 813
Drive wheel pressure, kg/mm
2
0,22 0,22 0,22 0,22
Castor wheel pressure, kg/mm
2
0,30 0,32 0,30 0,32
Support arm wheel pressure, boggie (4), kg/mm
2
0,40 0,40 0,40 0,41
Support arm wheel, single (2), kg/mm
2
0,59 0,60 0,60 0,61
1) For Large and Large sideways battery change
●
●
●
