Vehicle Care 259
4. Remove bulb form the holder.
Push the bulb into the socket
slightly to insert the bulb.
5. Insert the bulb holder into the
tail light assembly and connect
the electrical connector. Close
the cover and engage.
6. Switch on the ignition, operate
and check all lights.
Bumper Lights
1. Behind the rear bumper,
unscrew the screw to remove
bumper light assembly and
disconnect the electrical
connector.
2. Unscrew the both screws to
remove the bulb holder.
3. Rear Fog light (1) — if
equipped
Reverse light (2)
4. Insert and turn the bulb into the
bulb holder and screw it into
place. Install the bumper light
assembly in body and tighten
the screw. Connect the
electrical connector.
5. Switch on the ignition, operate
and check all lights.
Center High-Mounted
Stoplamp (CHMSL)
Have the light replaced by a
Chevrolet dealer.
