86 Instruments and Controls
Tachometer
Displays the engine revolutions per
minute (rpm).
Drive in a low engine speed range
for each gear as much as possible.
Caution
If the needle is in the red warning
zone, the maximum permitted
engine speed is exceeded.
Engine at risk.
Fuel Gauge
Displays the fuel level in the tank.
If the level in the tank is low, the
control indicator
. illuminates, the
chime comes on and the Driver
Information Center also displays a
message.
Refuel immediately.
Never run the tank dry.
Because of the fuel remaining in the
tank, the top-up quantity may be
less than the specified tank
capacity.
The arrow
q near the symbol .
indicates that the fuel filler door is
on the left side of the vehicle.
Note
Before refueling, make sure that the
ignition is off.
If you operate the ignition switch
while refueling, the needle of the
fuel gauge may not indicate the
proper fuel level.
On uphill and downhill slopes, the
needle on the fuel gauge may not
indicate the proper fuel level due to
movements of the fuel in the
fuel tank.
Control Indicators
The control indicators described are
not present in all vehicles. The
description applies to all instrument
versions. When the ignition is
switched on, most control indicators
will illuminate briefly as a
functionality test.
The control indicator colors mean:
Red : Danger, important reminder
