Step 6
For configuration instructions about using the CLI setup program, see the (Link to Running the Bootup script
section).
Rack Mounting the Controller
To prevent bodily injury when mounting or servicing this unit in a rack, you must take special precautions
to ensure that the system remains stable. The following guidelines are provided to ensure your safety:
Warning
•
This unit should be mounted at the bottom of the rack if it is the only unit in the rack.
•
When mounting this unit in a partially filled rack, load the rack from the bottom to the top with the
heaviest component at the bottom of the rack.
•
If the rack is provided with stabilizing devices, install the stabilizers before mounting or servicing
the unit in the rack.
Statement 1006
Take care when connecting units to the supply circuit so that wiring is not overloaded. Statement 1018.Warning
To mount the controller in a 19-inch equipment rack, you can order an optional Optional Rack Mount kit
(AIR-CT3504-RMNT= Cisco 3504 Wireless Controller Rack Mount Tray).
The rack-mount tray is designed for tool-less assembly. To rack-mount the controller, perform the following
steps:
Procedure
Step 1
Remove the four rubber feet if previously installed.
Step 2
Slide the Cisco 3504 Wireless Controller in position such that the 4-tray tabs align and latch into the bottom
of the unit as it is pushed in place. The front of the Cisco 3504 Wireless Controller should be flush against
Cisco 3504 Wireless Controller Installation Guide
16
Installing the Cisco 3504 Wireless Controller
Mounting the Controller
