Cisco Catalyst 4900 Series User Manual

Chapter 4 Transceiver Modules
X2 Modules
4-2
Catalyst 4900 Series Switch Installation Guide
78-18039-02
Note You must insert the SFP with the latching mechanism reversed on SFP port 46 and
port 48.
Figure 4-1 Connecting LC Connectors to the SFP Module (Catalyst 4948)
X2 Modules
You must connect the cables and install the X2 modules as shown in Figure 4-2
and Figure 4-3. More general installation information is in the 10-Gigabit
Ethernet X2 Transceiver Installation Note at the following location:
http://www.cisco.com/en/US/products/hw/modules/ps5455/prod_installation_gu
ide09186a00803469ed.html
For compatibility information, refer to the 10-Gigabit Ethernet Transceiver
Modules Compatibility Matrix at the following location:
http://www.cisco.com/en/US/products/hw/modules/ps5455/products_device_sup
port_table09186a00803857e7.html
113146
CON
AUX
45 46 47 48
Catalyst 4948
