B-3
Catalyst 4900 Series Switch Installation Guide
78-18039-02
Appendix B Initial Configuration for the Switch
Starting the Terminal-Emulation Software
Starting the Terminal-Emulation Software
Before you power on the switch, start the terminal-emulation session so that you
can see the output display from the power-on self-test (POST).
The terminal-emulation software—frequently a PC application such as
Hyperterminal or ProcommPlus—makes communication between the switch and
your PC or terminal possible.
Step 1 Start the terminal-emulation program if you are using a PC or terminal.
Step 2 Start a terminal-emulation session.
Step 3 Configure the baud rate and character format of the PC or terminal to match these
console port default characteristics:
• 9600 baud
• 8 data bits
• 1 stop bit
• No parity
• None (flow control)
Connecting to a Power Source
Follow these steps to connect to a power source:
Step 1 If you are using an AC power supply, connect one end of the supplied AC power
cord to the power connector on the switch rear panel, and then connect the other
end of the power cable to a grounded AC outlet. (See
Figure B-1.)
Step 2 If you are using a DC power supply, see the “Connecting DC Power to the Switch”
section on page 3-11 for instructions on how to install the DC power supply.
As the switch powers on, it begins the POST, a series of tests that runs
automatically to ensure that the switch functions properly.
