Cisco Catalyst IW6300 Series User Manual

Figure 15: Assembled Pole Clamp Bracket and Strap Brackets
Pole clamp bracket2M8 x1.25x16 bolts (with lock washers)1
Strap bracket (shown positioned for 11 to
16 inch diameter pole)
3
Step 2 Screw the M8 nut onto the pole clamp bracket support bolt, and tighten just enough to prevent the bolt from
falling off.
Step 3 Go to Pole Mounting, on page 28.
Pole Mounting
To mount your access point on a vertical pole, you need to install two metal bands around the pole to support
the access point. This process requires extra tools and material not provided in the pole mount kit (see the
following table).
Cisco Catalyst IW6300 Heavy Duty Series Access Point Hardware Installation Guide
28
Installing the Access Point
Pole Mounting
