Cisco Industrial Routers and Industrial Wireless Access Points Antenna Guide
http://www.cisco.com/c/en/us/support/wireless/aironet-antennas-accessories/products-installation-guides-list.html
Follow all safety precautions when installing the antennas. For information on safety, see Safety Precautions
When Installing Antennas, on page 18.
Antenna Selection Examples
The following examples list suggested antenna and RF accessory selections for typical installation scenarios.
Antenna
Mode
Configuration
InstallationLightning
Arrestors and/or
Adapters
Coaxial CablesAntennasUse Case
Dual bandConnect antennas directly
to ports A and B. Cap
ports C and D with
weatherproof caps.
NoneNone2x Dual-Band
Omni-Directional
Antennas
AIR-ANT2547V-N,
AIR-ANT2547VG-N,
AIR-ANT2547V-N-HZ,
or AIR-ANT2568VG-N
Omnidirectional
access coverage
on both radios
Single bandConnect the two 2.4 GHz
omnidirectional antennas
directly to ports A and B.
Mount the 5 GHz
directional antenna with
the included hardware
and connect it to ports C
and D via the adapters,
coaxial cables, and
lightning arrestors (if
required).
2x N(m)-N(f)
Lightning Arrestor
CGR-LA-NM-NF
and
2x N(f)-N(f)
adapter
AIR-ACC370-NF-NF
2x N(m) – N(m) cables:
CAB-L400-5-N-N
CAB-L400-5-N-NS
CAB-L400-20-N-N
CAB-L600-30-N-N
or
AIR-CAB025HZ-N
2x Dual-Band
Omni-Directional
Antennas
AIR-ANT2547V-N,
AIR-ANT2547VG-N,
AIR-ANT2547V-N-HZ,
or AIR-ANT2568VG-N
or 2x 2.4 GHz 5 dBi
Omnidirectional
Antennas
AIR-ANT2450V-N,
AIR-ANT2450VG-N,
AIR-ANT2450V-N-HZ,
or AIR-ANT2450HG-N
or 2x 2.4 GHz 8 dBi
Omnidirectional
Antennas
AIR-ANT2480V-N and
1x 5 GHz 13 dBi
Directional Antenna
AIR-ANT5114P2M-N=
Omnidirectional
access on 2.4
GHz, backhaul on
5 GHz
Cisco Catalyst IW6300 Heavy Duty Series Access Point Hardware Installation Guide
36
Installing the Access Point
Antenna Selection Examples
