APPENDIX C
Access Point Pinouts
• Access Point Pinouts , on page 73
Access Point Pinouts
This appendix describes the pin signals of the access point Ethernet connectors, and the power injector input
and output connectors. The following table describes the pin signals of the access point PoE Out connector.
Table 11: Access Point PoE Out Ethernet Connector Pinouts
Signal NamePin
Number
Ethernet signal pair (10/100/1000BASE-T) and VDC return1
2
Ethernet signal pair (10/100/1000BASE-T) and VDC (+)
3
6
Ethernet signal pair (10/100/1000BASE-T)
4
5
Ethernet signal pair (10/100/1000BASE-T)
7
8
Chassis ground
Shield
The following table describes the pin signals for the access point PoE In Ethernet connector.
Cisco Catalyst IW6300 Heavy Duty Series Access Point Hardware Installation Guide
73
