Cisco Content Delivery Engine 205/220/250/280/285/420/460/475 Hardware Installation Guide
Chapter 1 Overview of the Content Delivery Engines
Hardware Features
CDE285 Hardware Overview
Note The CDE285 engine is supported only for the OMD Software Applications.
The CDE285 ships with the following components installed:
• 2 Intel Xeon 3.20 GHz E5-2667 v4 series processor.
• 2 onboard copper Gigabit Ethernet ports.
• 2 hot-swappable redundant power supplies:
– AC power supplies (1200 W AC each).
– DC power supplies (930W -48V DC Common Power Supply).
• For CDE285-S, 8x16GB RDIMM (RAM) 128GB.
• For CDE285-L, 8x32GB RDIMM (RAM) 256GB.
Note For more details about the CDE285-S hardware overview, see Cisco UCS C240 M4 High-Density Rack
Server (Small Form Factor Disk Drive Model).
Note For more details about the CDE285-L hardware overview, see Cisco UCS C240 M4 High-Density Rack
Server (Large Form Factor Disk Drive Model)
CDE280-2H1 CDE280-K9 +
SB-CDE280-2H1
1 x 600 SAS 96GB VDS-IS 4.1.1 8 (10GE) Ports SFP+
CDE280-2H13 CDE280-K9 +
SB-CDE280-2H13
24 x 600 SAS 96GB VDS-IS 4.1.1 8 (10GE) Ports SFP+
CDE280-2H26 CDE280-K9 +
SB-CDE280-2H26
24 x 1200 SAS 96GB VDS-IS 4.1.1 8 (10GE) Ports SFP+
CDE280-2U1 CDE280-K9
SB-CDE280-2U1
24 x 400 SAS 96GB VDS-TV 4.2.0 8(10GE)PORTS SFP+
CDE280-2U2 CDE280-K9
SB-CDE280-2U2
24 x 480 SATA 96GB VDS-TV 4.2.0 8(10GE)PORTS SFP+
CDE280-2U3 CDE280-K9
SB-CDE280-2U3
24 x 800 SAS 96GB VDS-TV 4.2.0 8(10GE)PORTS SFP+
CDE280-2V0 CDE280-K9 +
SB-CDE280-2V0
— 96GB VQE 3.11 8 (10GE) Ports SFP+
CDE280-2U4 CDE280-K9
SB-CDE280-2U4
12 x 480 SATA 96GB VDS-TV 4.4.0 8(10GE)PORTS SFP+
Table 1-7 Supported CDE280 Configurations
CDE PID Drives RAM Product Name
Hardware
Support
First
Introduced NIC
