Cisco Content Delivery Engine 205/220/250/280/285/420/460/475 Hardware Installation Guide
Chapter 1 Overview of the Content Delivery Engines
Hardware Features
CDE420 Hardware Overview
The CDE420 ships with the following components installed:
• 2 Quad Core Intel Xeon (Harpertown L5410) CPUs @ 2.33 GHz
• 2 onboard copper Gigabit Ethernet NICs, 4-GB CF each (on 420 4A-C and 4A-F models)
• 3 onboard copper Gigabit Ethernet NICs, 4-GB CF each (on 420 4G-C and 4G-F models)
• 2 hot-swappable power supplies
• 32-GB RAM
• 1 8-GB CF + IDE adapter physically attached as IDE primary master
• 1 4-port Gigabit Ethernet adapter inserted into the third slot from the right (looking from rear)
• 1 SAS disk controller inserted into the far-right slot (looking from rear)
• 1 SAS disk controller inserted into the second slot from the right (looking from rear)
• 24 I-TB 3.5-inch SATA drives mounted to bay expanders designed to slide into the front of the
CDE420 chassis (on 420 4A-C and 420 4A-F models)
• 24 450-GB 3.5-inch SAS drives mounted to bay expanders designed to slide into the front of the
CDE420 chassis (on 420 4G-C and 4G-F models)
Note External drives and bay expanders are shipped separately and are not installed in the CDEs.
Table 1-9 shows the supported CDE420 configurations.
Table 1-8 Supported CDE285 Configurations
CDE PID Drives RAM
Product
Name NIC
CDE285-2S10 CDE285-S +
SB-CDE285-2S10
24 x 480 SSD 128GB OMD 8 (10GE) Ports SFP+
CDE285-2H26 CDE285-S +
SB-CDE285-2H26
24 x 1.2TB SAS 128GB OMD 8 (10GE) Ports SFP+
CDE285-2H40 CDE285-S +
SB-CDE285-2H40
24 x 1.8TB SAS 128GB OMD 8 (10GE) Ports SFP+
CDE285-2H90 CDE285-L +
SB-CDE285-2H90
12 x 8TB SAS 256GB OMD 8 (10GE) Ports SFP+
Table 1-9 Supported CDE420 Configurations
CDE PID Drives RAM Product Name
Hardware
Support
First
Introduced NIC
CDE420 4A-C CB-32-24A1T-2QTX 24 1-TB SATA 32 GB Vault CDS-TV 3.0 2 Quad (8 GE) Copper
CDE420 4A-F CB-32-24A1T-2QSX 24 1-TB SATA 32 GB Vault CDS-TV 3.0 2 Quad (8 GE) Fiber
