Cisco Content Delivery Engine 205/220/250/280/285/420/460/475 Hardware Installation Guide
Chapter 2 Preparing to Install the Content Delivery Engines
Safety Guidelines
The CDE280 grounding conductor consists of two screws that are mounted on the rear of the chassis (see
Figure 2-2).
Figure 2-2 CDE280 Rear View
For information about the CDE285 grounding connections, see Cisco UCS C240 M4 Server Installation
and Service Guide.
For the CDE420 grounding conductor consists of two screws that are mounted on the rear of the chassis
(see Figure 2-3).
Figure 2-3 CDE420 Rear View
1 Grounding-lug holes
1 Grounding screws
