Cisco NCS 1002 User Manual

CHAPTER 2
Alarm Troubleshooting
This chapter gives a description, severity, and troubleshooting procedure for each commonly encountered
Cisco NCS 1002 alarm and condition. When an alarm is raised, refer to its clearing procedure.
• Alarm Logical Objects, on page 45
• Alarm Severity, on page 46
• Alarms, on page 46
Alarm Logical Objects
Alarms are raised against logical objects. These logical objects represent physical objects such as cards, ports,
and logical objects such as trunk.
The table below lists all logical alarm objects used in this chapter.
Table 1: Alarm Logical Object Type Definitions
DefinitionLogical Object
Fan-tray assembly.FT
Pluggable port module (PPM, also called SFP), referring to MXP and TXP cards.PPM
Power Supply Unit.PSU
Chassis equipment.Chassis
Ethernet.Client
Temperature Sensor.Temp Sensor
Voltage Sensor.Voltage Sensor
DWDMTrunk
