Configuring VPN
Configuring Site-to-Site IPsec VPN Advanced Parameters
Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 101
6
Configuring Site-to-Site IPsec VPN Advanced Parameters
Advanced VPN parameters such as IKE and other VPN policies control how the
device initiates and receives VPN connections.
To configure advanced VPN parameters, choose VPN > Site-to-Site IPsec VPN >
Advanced VPN Setup.
Managing IKE Policies
The Internet Key Exchange (IKE) protocol dynamically exchanges keys between
two IPsec hosts. You can create IKE policies to define the security parameters to
be used when exchanging data with the remote router over the IPsec VPN
connection. For example, you can create IKE policies to define parameters for peer
authentication and encryption algorithms. Ensure that the encryption,
authentication, and key-group parameters in your VPN policy. are compatible with
settings at the remote router.
To add an IKE policy:
STEP 1 On the Advanced VPN Setup page, click Add Row.
STEP 2 Enter a unique name for the IKE policy to identify and manage the policy easily.
STEP 3 In the Exchange Mode field, choose one of the following modes for the policy:
• Main—Negotiates the tunnel with higher security, but is slower.
• Aggressive—Establishes a faster connection, but with lowered security.
STEP 4 In the Local Identifier and Remote Identifier fields, indicate if you want to identify
your device and the remote router by their real IP address or their public IP
address. If you select IP address, enter the real IP address of your device and the
remote router.
STEP 5 In the IKE SA Parameters section, configure parameters to define the strength and
mode for negotiating Security Association (SA) between your device and the
remote router:
a. In the Encryption Algorithm field, choose the algorithm to encrypt data.
b. In the Authentication Algorithm field, specify the authentication algorithm for
the VPN header. Ensure that the authentication algorithm is configured
identically on both sides of the VPN tunnel.

Cisco RV130W Specifications

General

DSL WAN	-
Ethernet WAN	Yes
SIM card slot	No
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1D, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
USB 2.0 ports quantity	1
Supported network protocols	DHCP, PPPoE, PPTP, L2TP, DNS, IGMP, RSTP
Antennas quantity	2
Security algorithms	WEP, WPA, WPA2-PSK
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power, USB, WAN, WLAN
Output voltage	12 V
Power source type	DC
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 85 %
