Cisco RV130W Administration Guide

Managing Your Device
Restarting the Device
Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 135
8
Changing the Language
To change the language on the device:
STEP 1 Choose Administration > Firmware/Language Upgrade.
STEP 2 In the File Type field, click the Language File button.
STEP 3 Click Browse to locate and select the language file.
STEP 4 (Optional) To restore the device configuration parameters to factory default values,
select Reset all configuration/settings to factory defaults.
STEP 5 Click Start Upgrade.
Restarting the Device
To restart the router:
STEP 1 Choose Administration > Reboot.
STEP 2 Click Reboot.
Restoring the Factory Defaults
!
CAUTION During a restore operation, do not try to go online, turn off the router, shut down the
PC, or use the router until the operation is complete. This should take about a
minute. When the test light turns off, wait a few more seconds before using the
router.

Cisco RV130W Specifications

General

DSL WAN	-
Ethernet WAN	Yes
SIM card slot	No
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1D, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
USB 2.0 ports quantity	1
Supported network protocols	DHCP, PPPoE, PPTP, L2TP, DNS, IGMP, RSTP
Antennas quantity	2
Security algorithms	WEP, WPA, WPA2-PSK
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power, USB, WAN, WLAN
Output voltage	12 V
Power source type	DC
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 85 %
