Cisco RV130W Administration Guide

Configuring VPN
Configuring IPsec VPN Server
Cisco RV130/RV130W Wireless Multifunction VPN Router Administration Guide 105
6
Configuring IPsec VPN Server
Using IPsec VPN enables secure remote access to corporate resources by
establishing an encrypted tunnel across the Internet. Your device supports the
following IPsec VPN clients:
• TheGreenBow
• ShrewSoft
Configuring the IPsec VPN Server
To configure the IPsec VPN server:
STEP 1 Choose VPN > IPsec VPN Server> Setup.
STEP 2 Check the Server Enable check box.
STEP 3 In the Phase 1 section, configure settings to authenticate the two VPN endpoints to
each other and negotiate the IKE Security Association (SA) so that a secure
channel is set up for negotiating SAs in Phase 2.
a. In the Pre-Shared Key field, enter the pre-shared key or password that will be
exchanged between your device and the remote endpoint. The password
must be between 8 and 49 characters.
b. In the Exchange Mode field, choose one of the following modes for the IPsec
VPN connection:
- Main—Negotiate the tunnel with higher security, but is slower.
- Aggressive—Establish a faster connection, but with lowered security.
c. Choose the Encryption Algorithm to encrypt data and choose the
Authentication Algorithm for the VPN header. Ensure that the authentication
algorithm is configured identically on both your device and the remote
endpoint.
d. In the Diffie-Hellman (DH) Group field, specify the Diffie-Hellman Group
algorithm used when exchanging a pre-shared key sets the strength of the
algorithm in bits. Ensure that the DH Group is configured identically on both
your device and the remote endpoint.
e. In the IKE SA-Lifetime field, enter the duration, in seconds, after which the
Security Association for the VPN connection is renegotiated.

Cisco RV130W Specifications

General

DSL WAN	-
Ethernet WAN	Yes
SIM card slot	No
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1D, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
USB 2.0 ports quantity	1
Supported network protocols	DHCP, PPPoE, PPTP, L2TP, DNS, IGMP, RSTP
Antennas quantity	2
Security algorithms	WEP, WPA, WPA2-PSK
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power, USB, WAN, WLAN
Output voltage	12 V
Power source type	DC
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 85 %
