Configuring Multicast Forwarding
Querying IGMP/MLD IP Multicast Group
Cisco Small Business 200 Series Smart Switch Administration Guide 204
15
Querying IGMP/MLD IP Multicast Group
The
IGMP/MLD IP Multicast Group
page displays the IPv4 and IPv6 group address
learned from IGMP/MLD messages.
There might be a difference between information on this page and, for example,
information displayed in the
MAC Group Address
page
.
Assuming that the system
is in MAC-based groups and a port that requested to join the following Multicast
groups 224.1.1.1 and 225.1.1.1, both are mapped to the same MAC Multicast
address 01:00:5e:01:01:01. In this case, there is a single entry in the
MAC Multicast
page, but two entries on this page.
To query for a IP Multicast group:
STEP 1 Click Multicast > IGMP/MLD IP Multicast Group. The IGMP/MLD IP Multicast
Group page opens.
STEP 2 Set the type of snooping group for which to search: IGMP or MLD.
STEP 3 Enter some or all of following query filter criteria:
• Group Address equals to—Defines the Multicast group MAC address or IP
address to query.
• Source Address equals to—Defines the sender address to query.
• VLAN ID equals to—Defines the VLAN ID to query.
STEP 4 Click Go. The following fields are displayed for each Multicast group:
• VLAN—The VLAN ID.
• Group Address—The Multicast group MAC address or IP address.
• Source Address—The sender address for all of the specified group ports.
• Included Ports—The list of destination ports for the Multicast stream.
• Excluded Ports—The list of ports not included in the group.
• Compatibility Mode—The oldest IGMP/MLD version of registration from the
hosts the switch receives on the IP group address.
