Configuring Discovery
Configuring CDP
Cisco Small Business 200 Series Smart Switch Administration Guide 99
8
• Capabilities—Primary functions of the device. The capabilities are indicated
by two octets. Bits 0 through 7 indicate Other, Repeater, Bridge, WLAN AP,
Router, Telephone, DOCSIS cable device, and station respectively. Bits 8
through 15 are reserved.
• Platform—Identifier of the neighbor’s platform.
• Neighbor Interface—Interface number of the neighbor through which frame
arrived.
• Native VLAN—Neighbor’s native VLAN.
• Duplex—Whether neighbors interface is half or full duplex.
• Addresses—Neighbor’s addresses.
• Power Drawn—Amount of power consumed by neighbor on the interface.
• Version—Neighbor’s software version.
NOTE Clicking on the Clear Table button disconnect all connected devices if from CDP,
and if Auto Smartport is enabled change all port types to default.
Viewing CDP Statistics
The CDP Statistics page displays information regarding Cisco Discovery Protocol
(CDP) frames that were sent or received from a port. CDP packets are received
from devices attached to the switches interfaces, and are used for the Smartport
feature. See Configuring CDP for more information.
CDP statistics for a port are only displayed if CDP is enabled globally and on the
port. This is done in the CDP Properties page and the CDP Interface Settings
page.
To v i e w C D P s t a t i s t i c s :
STEP 1 Click Administration > Discovery - CDP > CDP Statistics. The CDP Statistics page
opens.
The following fields are displayed for every interface:.
Packets Received/Transmitted:
• Version 1—Number of CDP version 1 packets received/transmitted.
• Version 2—Number of CDP version 2 packets received/transmitted.
• Total—Total number of CDP packets received/transmitted.
