Configuring Discovery
LLDP and CDP
Cisco Small Business 200 Series Smart Switch Administration Guide 70
8
By default, Bonjour is enabled on all interfaces that are members of the
Management VLAN.
To globally enable Bonjour:
STEP 1 Click Administration > Discovery - Bonjour. The Discovery - Bonjour page
opens.
STEP 2 Select Enable to enable Bonjour Discovery globally on the switch.
STEP 3 Click Apply. Bonjour is enabled or disabled on the switch according to the
selection.
LLDP and CDP
LLDP (Link Layer Discovery Protocol) and CDP (Cisco Discovery Protocol) are link
layer protocols for directly-connected LLDP and CDP-capable neighbors to
advertise themselves and their capabilities to each other. By default, the switch
sends an LLDP/CDP advertisement periodically to all its interfaces and terminates
and processes incoming LLDP and CDP packets as required by the protocols. In
LLDP and CDP, advertisements are encoded as TLV (Type, Length, Value) in the
packet.
The following CDP/LLDP configuration notes apply:
• CDP/LLDP can be globally enabled or disabled and enabled/disabled per
port. The CDP/LLDP capability of a port is relevant only if CDP/LLDP is
globally enabled.
• If CDP/LLDP is globally enabled, the switch filters out incoming CDP/LLDP
packets from ports that are CDP/LLDP-disabled.
• If CDP/LLDP is globally disabled, the switch can be configured to discard,
VLAN-aware flooding, or VLAN-unaware flooding of all incoming CDP/LLDP
packets. VLAN-aware flooding floods an incoming CDP/LLDP packet to the
VLAN where the packet is received excluding the ingress port. VLAN-
unaware flooding floods an incoming CDP/LLDP packet to all the ports
excluding the ingress port. The default is to discard CDP/LLDP packets
when CDP/LLDP is globally disabled. You can configure the discard/
flooding of incoming CDP and LLDP packets from the CDP Properties page
and the LLDP Properties page respectively.
