Clarion NX602 Owner's Manual & Installation Manual

English
12
NX602
At all mode, long press [ALL] button to
enter main source menu. Touch [Custom]
on the bottom left of the screen, then select
[Settings] on the screen to enter Setting
menu. Touch the icons on the left of screen
to select category: General, Time, Sound,
Display or Setup. To exit Setting menu, touch
[ ] on the bottom left of the screen.
General
Systemlanguage
Touch the button to the right of “System
language” to show language list. Select
desired language, touch [OK] to confirm, or
touch [Cancel] to exit without saving.
Closeoperationbar
When select [Auto], the operation bar will
close automatically after 10 seconds.
When select [Manual], the operation bar will
not close unless you touch the blank area on
the screen.
MainMenuIcons
When select [Active], main menu show
animation icons.
When select [Simple], main menu show
simple icons.
KeyIllumination
Touch [Set] to the right of “Key Illumination”
to show key illumination setting menu.
ScanColor: Scan 12 preset button backlight,
touch [Enter] to select desired one.
Edit Color: There are 12 preset colors and
3 custom colors, you can select one color by
touch Color 1~12 or Custom 1~3.
Touch [Adjust] to show edit color menu.
Drag the color bar or inputting the RGB value
to select one color, touch [Enter] to conrm.
Initialize: Load original Buttons backlight.
Touch [MENU] on the top left of the screen to
return to main setting menu.
Wallpaperimages
Touch [Set] to the right of “Wallpaper images”
to show Wallpaper setting menu.
Touch [
] or [ ] button to select the scene,
and touch the picture le name on the right
to preview it, then touch [Set] to conrm the
setting.
Touch [Import] to import the images from
mobile storage.
Beep
Touch [On] or [Off] to turn on/off the key beep
sound.
BlinkingLED
Touch [On] or [Off] to turn on/off the blinking
LED.
At blinking LED [On] mode, when ACC off,
the LED on the top left of the panel will blink.
Screencalibration
Touch [Set] to calibrate the screen.
Systemsoftware
Touch [Version] to show current software
version.
Restorefactorydefault
Touch [Restore] to load the original factory
settings.
Time
GPSsync
Touch [On] to synchronize time with GPS
and the following settings are disable: “Date”
and “Time”.
Date
Touch the button to the right of “Date” to
show date setting menu. Touch [
] or [ ]
to select month, date or year. Touch [Set] to
conrm or [Back] to exit without saving.
Dateformat
Touch the button to the right of “Date format”
to select a date format from the sub-menu.
Time
Touch the button to the right of “Time” to
show time setting menu. Touch [ ] or [ ]
button to select hour or minute. Touch [Set]
to conrm or [Back] to exit without saving.
6. SYSTEM SETUP
