Clarion NX602 Owner's Manual & Installation Manual

English
20
NX602
MP3/WMA Playback
This unit is an ID3 Tag compatible model.
This unit supports the ID3 TAGs of the
Version 2.4, 2.3, 1.1 and 1.0.
In displaying, this unit gives priority to the
Version 2.3 and 2.4 TAGs.
What is MP3/WMA
MP3 is an audio compression method
and classied into audio layer 3 of MPEG
standards.
WMA is an audio compression method
developed by Microsoft Corporation.
These audio compression methods have
penetrated into PC users and become a
standard format.
These features compress the original audio
data to about 10 percent of its initial size with
a high sound quality. This means that about
10 music CDs can be recorded on a CD-R
disc or CD-RW disc to allow a long listening
time without having to change CDs.
Note: Some CDs recorded on CD-R/RW
mode may not be usable.
Displaying MP3/WMA TAG titles
Tag information such as title, artist and
album title can be displayed for MP3/WMA
le containing Tag information.
Precautions when creating MP3/
WMA le
Usablesamplingratesandbitrates
1. MP3: Sampling rate 8 kHz-48 kHz, Bit rate
8 kbps-320 kbps / VBR
2. WMA: Bit rate 8 kbps-320 kbps
Fileextensions
1. Always add a file extension “.MP3”,
“.WMA” to MP3, WMA le by using single
byte letters. If you add a file extension
other than specified or forget to add the
le extension, the le cannot be played.
2. Files without MP3/WMA data will not play.
The les will be played soundlessly if you
attempt to play files without MP3/WMA
data.
* When VBR les are played, the play time
display may differ the play location.
* When MP3/WMA les are played, a little
no sound part is caused between tunes.
Logicalformat(Filesystem)
1. When writing MP3/WMA file on a CD-R
disc or C D-R W di sc, please select
“ISO9660 level 1, 2 or Joliet or Romeo” or
Apple ISO as the writing software format.
Normal play may not be possible if the
disc is recorded on another format.
2. The folder name and file name can be
displayed as the title during MP3/WMA
play but the title must be within 32 single
byte alphabetical letters and numerals
(including an extension).
3. Do not afx a name to a le inside a folder
having the same name.
Folderstructure
A disc with a folder having more than 8
hierarchical levels will be impossible.
Numberoflesorfolders
1. Up to 999 files can be recognized per
folder.
Up to 3000 les can be played.
2. Tracks are played in the order that they
were recorded onto a disc. (Tracks
may not always be played in the order
displayed on the PC.)
3. Some noise may occur depending on
the type of encoder software used while
recording.
PlayingMP3folders
When selected for play, files and folders
(Folder Search, File Search or Folder Select)
are accessing in the order in which they were
written to the media.
As a result, the order in which they are
expected to be played may not match the
order in which they are actually played.
You may be able to set the order in which
MP3/WMA les are to be played by assigning
file names beginning with play sequence
numbers such as “01” to “99”.
For example, a medium with the following
folder/file hierarchy is subject to Folder
Search, File Search or Folder Select.
See the diagram below.
