Communication Guide, ©ComAp – March 2014 25
IGS-NT Communication Guide 03-2014.pdf
Selection of CAN address. Open = ADDR1, Close = ADDR2
It is possible to use up to two I-LB+ devices in direct mode on CAN(2)
bus. Let jumper open in case of using one I-LB+ module. Other I-LB
module has to have this jumper closed. (read more about I-LB+ module)
Selection of communication port (jumper is in RS232 or RS485 position)
Open = terminator not connected, Close = terminator connected
Open = terminator not connected, Close = terminator connected
Controllers
RS232 on I-
LB+
RS485 on I-
LB+
RS232 on I-
LB+
RS485 on I-
LB+
RS232 on I-
LB+
RS485 on I-
LB+
RS232 on I-
LB+
RS485 on I-
LB+
RS232 on I-
LB+
RS485 on I-
LB+
RS232 on I-LB+
RS485 on I-LB+
RS232 on I-LB+
RS485 on I-LB+
RS232 on I-LB+
RS485 on I-LB+
RS232 on I-LB+
RS485 on I-LB+
Equipment
RS232 connection or RS232/USB converter
RS485 connection or RS485/USB converter
