Gear teeth [-]
Number of teeth on the engine gear for the pick-up.
Set to zero, if no pick-up is used. Engine speed is counted from the generator frequency.
Step: 1
Range: 0 – 500
Hint:
Generator frequency can be used only when generator voltage (min 5V) is present before reaching of
the firing speed (Starting RPM) after start.
Nominal RPM [RPM]
Nominal engine speed.
Step: 1RPM
Range: 100 – 4000 RPM
FltRes GoToMAN [ENABLED/DISABLED]
DISABLED: Controller stays in AUT mode after Fault reset .
ENABLED: Automatic switch from AUT (or TEST) to MAN mode after Fault reset to avoid
automatic engine start. This function is active for Shut down protection only.
DispBaklightTO [min]
Timeout after which the display backlight is switched off.
Step: 1 min
Range: 0 – 60 min
Default value: 0 … means that the display lights all the time
ControllerMode [ OFF, MAN, AUT ]
Equivalent to Controller mode changes by MODE→ or ←MODE buttons.
Hint:
Controller Mode change can be separately password protected.
* RS232 mode [STANDARD/MODBUS/CumminsMB]
Communication protocol switch.
Standard: LiteEdit communication protocol.
Modbus: Modbus protocol.
CumminsMB: Protocol for communication with Cummins engines via Modbus.
Hint:
For detail description see chapter Modbus protocol.
*NumberRings AA [ - ]
Number of rings prior to open modem connection.
Step: 1
Range: 1 – 30
Hint:
NumberRings AA change is not activated immedatelly. It is activated after controller is switched on or
when modem is connected to controller.
Engine params
Start RPM [%]
“Firing” speed when iL controller stops cranking (starter goes OFF).
Step: 1% of nominal RPM
Range: 5 – 50 %
InteliLite – MRS10/11/15/16, SW version 2.2, ©ComAp – November 2004 29
