How to select the gen-set mode ?
Use MODE→ or ←MODE to select requested gen-set operation mode
(OFF – MAN – AUT)
^When to use buttons GCB ON/OFF?
In AUT mode these buttons are disabled.
In MAN mode are enabled, but before closing of any circuit beaker, voltage must be within limits.
Internal protection against closing of both circuit breakers is implemented.
Display menus
There are 2 display menus available: MEASUREMENT and ADJUSTMENT
Each menu consists of several screens. Press repeatedly PAGE button to select requested menu.
How to view measured data?
1. Use repeatedly PAGE button to select the MEASUREMENT menu.
2. Use ↑ and ↓ to select the screen with requested data.
How to view and edit set points?
1. Use repeatedly PAGE button to select the ADJUSTMENT menu.
2. Use ↑ or ↓ to select requested set points group.
3. Press ENTER to confirm.
4. Use ↑ or ↓ to select requested set point.
5. Set points marked “*” are password protected.
6. Press ENTER to edit.
7. Use ↑ or ↓ to modify the set point. When ↑ or ↓ is pressed for 2 sec, auto repeat function is
activated.
8. Press ENTER to confirm or PAGE to leave without change.
9. Press PAGE to leave selected set points group.
How to change the display contrast ?
Press ENTER and ↑ or ↓ at the same time to adjust the best display contrast
Hint:
Only in MEASUREMENT menu.
How to check the serial number and software revision?
Press ENTER and then PAGE. On the display you can see InteliLite INFO screen for 10 seconds.
InteliLite INFO screen contains :
1) Controller name (see Basic setting group)
2) InteliLite serial number (8 character number)
3) SW version: the first is the firmware version number, the second is configuration table
number.
4) Application: MRS16
5) Branch: Standard
Hint:
Only in MEASUREMENT menu.
How to find active alarms ?
Active alarm list is the last screen in the MEASUREMENT menu.
InteliLite – MRS10/11/15/16, SW version 2.2, ©ComAp – November 2004 45
