ComAp InteliLite MRS11 User Manual

JOHN DEERE
IL-CU binary output description John Deere 21 pin Deutsch connector
Start output D
Fuel output G (switched ECU power),J (ignition)
IL-CU CAN description John Deere 21 pin Deutsch connector
CAN bus common Screen for the J1939 cable.
CAN bus H V
CAN bus L U
CUMMINS ISB/ISBE
IL-CU binary output description Cummins ISB OEM Harness connector B
Start output connects directly to engine starter solenoid
Fuel output 39
IL-CU CAN description Cummins ISB 9 pin Deutsch connector
CAN bus common SAE J1939 shield - screen for J1939 cable.
CAN bus H SAE J1939 signal
CAN bus L SAE J1939 return
InteliLite – MRS10/11/15/16, SW version 2.2, ©ComAp – November 2004 42
IL-MRS-2.2.pdf
